Produktbeschreibung Audyn CO92/6.8/140 | 6,8 mH | 0,66 Ω | 5% | 15 AWG

A high-purity Crossover Component, the Audyn CO92/6.8/140 Corobar Coil.

Highlights

High inductance value of 6.8mH
Low resistance of 0.66 Ohms
Copper purity greater than 99.99%
Inductance tolerance of ± 5%

Product details

Audyn CO92/6.8/140 | 6,8 mH | 0,66 Ω | 5% | 15 AWG | Corobar Coil

This Audyn CO92/6.8/140 Corobar Coil is a copper foil coil belonging to the category of crossover components. The coil boasts a high inductance value of 6.8 millihenries and a low resistance of 0.66 ohms. The coil wire of the Audyn CO92/6.8/140 is made from copper with a purity of over 99.99%. One of the key features of this coil is the inductance tolerance of ± 5%. The wire connection length is 10/40mm and the tinning length is 9mm. The coil body is made from ABS material and the core form is Corobar. The coil is designed to operate optimally at a nominal temperature of 25 degrees Celsius. This coil is ideal for high performance audio crossover networks.

I.T. Intertechnik Artikelnummer: 1340950
