Name: Intertechnik AT55/068/132 | 0,68 mH | 0,26 Ω | 3% | 16 AWG | Choke Spule
Brand: Intertechnik
SKU: AT55/068/132
Price: 27.95 EUR
Availability: BackOrder

AT55/068/132 | 0,68 mH | 0,26 Ω | 3% | 16 AWG | Choke Spule

23,10 €27,95 € Nicht auf Lager

Backorder

Wir versenden nach
Bald wieder auf Lager
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik AT55/068/132 | 0,68 mH | 0,26 Ω | 3% | 16 AWG

The I.T. Intertechnik AT55/068/132 is a high-purity copper foil choke coil for crossover components.

Highlights

High copper purity of over 99.99%
Resistance of 0.26 Ohms
Inductance value of 0.68 mH
Thermoplastic insulation for enhanced stability

Product details

I.T. Intertechnik AT55/068/132 | 0,68 mH | 0,26 Ω | 3% | 16 AWG | Choke Coil

The I.T. Intertechnik AT55/068/132 is a high-quality, advanced choke coil, ideal for crossover components. It boasts a high copper purity of over 99.99%, ensuring optimal conductivity and performance. The coil provides an inductance of 0.68 mH and a resistance of 0.26 Ohms, offering precision and reliability. The coil features thermoplastic insulation for enhanced stability and performance under varying temperature conditions, ranging from -90 to 135 degrees Celsius. It comes with a nominal measurement value at 25 degrees Celsius and 1 kHz. In addition, the coil has a wire connection length of 50 mm and a tinning length of 9 mm. The coil body is made of polycarbonate, ensuring durability and longevity.

I.T. Intertechnik Artikelnummer: 1500072
