Name: Intertechnik CO30/010/090 | 0,1 mH | 0,10 Ω | 5% | 19 AWG | Choke Spule
Brand: Intertechnik
SKU: CO30/010/090
Price: 19.95 EUR
Availability: InStock

CO30/010/090 | 0,1 mH | 0,10 Ω | 5% | 19 AWG | Choke Spule

16,49 €19,95 € 2 Auf Lager

Wir versenden nach
Jetzt bestellt, morgen versandt
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik CO30/010/090 | 0,1 mH | 0,10 Ω | 5% | 19 AWG

This Choke Coil, I.T. Intertechnik CO30/010/090, is a high-quality component for advanced crossovers.

Highlights

0.1 mH inductance for precise sound filtering
High CU purity of > 99.99% for enhanced conductivity
Tolerance of - 3% for accurate performance
Durable Polycarbonate coil body resistant from -90 to 135 degrees Celsius

Product details

I.T. Intertechnik CO30/010/090 | 0,1 mH | 0,10 Ω | 5% | 19 AWG | Choke Coil

This Intertechnik CO30/010/090 Choke Coil is a superior choice for crossover coil applications. With an inductance of 0.1 mH and a resistance of 0.10 Ω, it offers precise and reliable sound filtering. The coil boasts a CU purity of more than 99.99%, ensuring enhanced electrical conductivity for superior performance. It features a durable Polycarbonate coil body that can withstand temperatures ranging from -90 to 135 degrees Celsius. The coil also comes with a tolerance of - 3%, measured at Nom. 25 degrees C and 1 kHz, making it extremely accurate and reliable. Its wire connection length is 50mm and the tin length is 9mm, providing ample space for easy installation. This is a 19 AWG coil, making it a robust choice for your crossover component needs.

I.T. Intertechnik Artikelnummer: 1500090
