      DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule

      Intertechnik DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule

      €49,95

      2 Auf Lager

      Zum Warenkorb hinzufügen

      Intertechnik DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule

      0 reviews
      0 von 5
      0 reviews
      5 Sterne
      0%
      4 Sterne
      0%
      3 Sterne
      0%
      2 Sterne
      0%
      1 Stern
      0%
      Alle Bewertungen anzeigen
      Marke: Intertechnik
      Zeige alle Kupferfolienspulen
      DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule
      DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule
      DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule
      DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule
      49,95 € 2 Auf Lager
      +-
      Zum Warenkorb hinzufügen
      • Wir versenden nach United States of America
      • Jetzt bestellt, heute versendet
      • Mindestens zwei Jahre Garantie
      • 45 Tage Widerrufsrecht
      • Kundenbewertung:
      Angebot anfordern
      DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule
      DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule
      DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule
      DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Spule

      Produktbeschreibung Intertechnik DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG

      The I.T. Intertechnik DR56/3.9/140 is a high-quality 3.9 mH copper foil coil with an inductance tolerance of 5% and a resistance of 0.206 Ω.



      Highlights

      • High copper purity of over 99.99% ensures excellent electrical conductivity.
      • Designed with a 10/40mm wire connection length and 9mm tin length.
      • Boasts a Ferrobar core providing superior magnetic properties.
      • Utilizes 15 AWG wire gauge for optimal power handling.



      Product details

      I.T. Intertechnik DR56/3.9/140 | 3,9 mH | 0,206 Ω | 5% | 15 AWG | Ferrobar Coil



      The I.T. Intertechnik DR56/3.9/140 is a premium quality crossover component from the renowned Copper Foil Coils category. With a high inductance of 3.9 mH and a resistance of 0.206 Ω, this coil ensures excellent signal transmission and minimal power loss. The inductance tolerance is a mere ±5%, providing consistent performance. The coil features a high copper purity of over 99.99%, guaranteeing superior electrical conductivity. The 10/40mm wire connection length and 9mm tin length offer flexibility and ease of installation. Built with a Ferrobar core, it provides superior magnetic properties, enhancing the coil's overall performance. To ensure optimal power handling, the coil utilizes a 15 AWG wire gauge. This coil is an excellent choice for high-performance audio crossover networks, offering exceptional performance and reliability.



      I.T. Intertechnik Artikelnummer: 1340836

      Eigenschaften

      Artikelnummer:
      DR56/3.9/140
      EAN
      8785256849963
      Spulen-Typ
      Copper foil coils
      Induktion
      3.9 mH
      Gleichstromwiderstand
      0.206 ohms
      Toleranz
      5%
      Kabeldurchmesser
      15 AWG

      Mehr anzeigen
