Name: Intertechnik HQR32/2.0/71 | 2,0 mH | 0,84 Ω | 5% | 21 AWG | Tube Core Spule
Brand: Intertechnik
SKU: HQR32/2.0/71
Price: 9.95 EUR
Availability: InStock

HQR32/2.0/71 | 2,0 mH | 0,84 Ω | 5% | 21 AWG | Tube Core Spule

8,22 €9,95 € 10 Auf Lager

Wir versenden nach
Jetzt bestellt, heute versendet
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik HQR32/2.0/71 | 2,0 mH | 0,84 Ω | 5% | 21 AWG

A high-quality, precision-engineered Tube Core Coil with exceptional purity and inductance characteristics.

Highlights

2.0 mH Inductance with 5% tolerance
21 AWG copper wire of >99.99% purity
Utilises Corobar or Ferrobar core structures
0.84 Ω resistance ensuring optimal performance

Product details

I.T. Intertechnik HQR32/2.0/71 | 2,0 mH | 0,84 Ω | 5% | 21 AWG | Tube Core Coil

Introducing the I.T. Intertechnik HQR32/2.0/71 Tube Core Coil, a high-performance component in the realm of crossover components and copper foil coils. Boasting a substantial inductance of 2.0 mH with a tight tolerance of 5%, it is designed for precision and reliability in a range of applications. The coil employs a 21 AWG copper wire, ensuring greater than 99.99% purity. This offers exceptional conductivity and minimises signal loss. The core is either Corobar or Ferrobar, offering superior magnetic properties and improved performance. With a resistance of 0.84 Ω, it guarantees optimal performance while maintaining low power consumption. The coil has a wire connection length of 10mm and a tinned length of 9mm, housed in an ABS spool body for added durability. Measured at a nominal 25 degrees C and 1 kHz, this Tube Core Coil is a testament to I.T. Intertechnik's commitment to quality and performance.

I.T. Intertechnik Artikelnummer: 1340256
