Name: Intertechnik HQR32/4.7/50 | 4,7 mH | 2,31 Ω | 5% | 24 AWG | Tube Core Spule
Brand: Intertechnik
SKU: HQR32/4.7/50
Price: 8.65 EUR
Availability: InStock

HQR32/4.7/50 | 4,7 mH | 2,31 Ω | 5% | 24 AWG | Tube Core Spule

7,15 €8,65 € 4 Auf Lager

Wir versenden nach
Vor 16:00 Uhr bestellt, heute versandt
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik HQR32/4.7/50 | 4,7 mH | 2,31 Ω | 5% | 24 AWG

An efficient copper foil coil, the I.T. Intertechnik HQR32/4.7/50 is ideal for crossover component applications.

Highlights

4.7 mH inductance with a 5% inductance tolerance
Resistance of 2.31 Ohms, ideal for high-performance applications
High purity copper wire (> 99.99%) for superior electrical conductivity
24 AWG wire size for optimal balance between size and electrical properties

Product details

I.T. Intertechnik HQR32/4.7/50 | 4,7 mH | 2,31 Ω | 5% | 24 AWG | Tube Core Coil

The I.T. Intertechnik HQR32/4.7/50 is a high-quality copper foil coil designed specifically for crossover components applications. The coil features an inductance of 4.7 mH, with an inductance tolerance of ±5%, and a resistance of 2.31 Ohms, making it perfect for use in high-performance applications. The coil utilizes a high purity copper wire that is greater than 99.99%, ensuring excellent electrical conductivity for superior performance. The coil also features a 24 AWG wire size, offering an optimal balance between size and electrical properties. The coil's core is either Corobar or Ferrobar, providing excellent magnetic properties. It is housed in an ABS spool body, ensuring durability and reliability. The coil has a copper wire diameter of 0.50 to 0.60 mm, and a tinning length of 9 mm, with a wire connection length of 10 mm.

I.T. Intertechnik Artikelnummer: 1340968
