    Produktbeschreibung Intertechnik LU32/012/071 | 0,12 mH | 0,28 Ω | 3% | 21 AWG

    The I.T. Intertechnik LU32/012/071 is a high-quality air core coil for audio crossover applications.



    Highlights

    • High CU purity of >99.99% for optimal conductivity.
    • Features a thermoplastic insulation and polycarbonate coil body.
    • Offers nominal inductance of 0.12 mH and resistance of 0.28 Ω.
    • Operating temperature range from -90 to 135 degrees Celsius.



    Product details

    I.T. Intertechnik LU32/012/071 | 0,12 mH | 0,28 Ω | 3% | 21 AWG | Choke Coil



    The I.T. Intertechnik LU32/012/071 is a robust air core coil designed for crossover applications. It features a high CU purity of >99.99% to ensure optimal electrical conductivity. The coil boasts a thermoplastic insulation and a polycarbonate coil body, ensuring durability and resistance to high temperatures, with an operating range from -90 to 135 degrees Celsius. The coil provides a nominal inductance of 0.12 mH and a resistance of 0.28 Ω, with a tolerance of 3%. This 21 AWG choke coil is meticulously engineered to deliver superior audio performance, making it an excellent choice for audio professionals and enthusiasts alike.



    I.T. Intertechnik Artikelnummer: 1340210

    Eigenschaften

    Artikelnummer:
    LU32/012/071
    EAN
    8785256849406
    Spulen-Typ
    Air core coils
    Induktion
    0.12 mH
    Gleichstromwiderstand
    0.28 ohms
    Toleranz
    3%
    Kabeldurchmesser
    21 AWG

    Mehr anzeigen
