Name: Intertechnik LU44/047/100 | 0,47 mH | 0,36 Ω | 3% | 18 AWG | Luftkernspule
Brand: Intertechnik
SKU: LU44/047/100
Price: 13.25 EUR
Availability: InStock

LU44/047/100 | 0,47 mH | 0,36 Ω | 3% | 18 AWG | Luftkernspule

10,95 €13,25 € 10+ Auf Lager

Wir versenden nach
Vor 16:00 Uhr bestellt, heute versandt
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik LU44/047/100 | 0,47 mH | 0,36 Ω | 3% | 18 AWG

The I.T. Intertechnik LU44/047/100 Air Coil is a high-quality crossover component with precise inductance and resistance values.

Highlights

Inductance value of 0.47 mH
Resistance value of 0.36 Ω
Inductance tolerance of 3%
Made from 18 AWG wire

Product details

I.T. Intertechnik LU44/047/100 | 0,47 mH | 0,36 Ω | 3% | 18 AWG |Air Coil

The I.T. Intertechnik LU44/047/100 is a top-of-the-line air coil designed for use in crossover components. It provides an inductance value of 0.47 mH with a resistance value of 0.36 Ω, ensuring precise and reliable performance. The coil is made from 18 AWG wire, presenting excellent durability and longevity. The inductance tolerance is 3%, ensuring consistency in your audio devices. Its wire connection length is 10 mm, with a tinning length of 9 mm. The coil core is made of ABS material, which offers superior heat resistance and stability. The inductance measurement is nominal at 25 degrees C at 1KHz, providing reliable performance across a wide range of operating conditions.

I.T. Intertechnik Artikelnummer: 1340018
