Name: Intertechnik LU55/010/140 | 0,1 mH | 0,08 Ω | 3% | 15 AWG | Luftkernspule
Brand: Intertechnik
SKU: LU55/010/140
Price: 11.45 EUR
Availability: InStock

LU55/010/140 | 0,1 mH | 0,08 Ω | 3% | 15 AWG | Luftkernspule

9,46 €11,45 € 4 Auf Lager

Wir versenden nach
Jetzt bestellt, heute versendet
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik LU55/010/140 | 0,1 mH | 0,08 Ω | 3% | 15 AWG

The I.T. Intertechnik LU55/010/140 is a high-quality air coil of 0.1mH inductance, with a resistance of 0.08 Ω.

Highlights

High-quality air coil with 0.1mH inductance
Low electrical resistance of 0.08 Ω
Exceptional tolerance of 3%
Constructed with a reliable 15 AWG wire

Product details

I.T. Intertechnik LU55/010/140 | 0,1 mH | 0,08 Ω | 3% | 15 AWG |Air Coil

The I.T. Intertechnik LU55/010/140 air coil is a top-notch product in the category of 'Crossover components Air core coils'. The coil, having an inductance of 0.1mH and an electrical resistance of 0.08 Ω, is designed to deliver optimal performance. The product's inductance tolerance is an impressive -3%, ensuring unwavering performance. The coil is constructed with a 15 AWG wire, promising durability and long-term usage. The coil's wire connection length is 10mm, with a tinning length of 9mm. The coil body material is ABS, adding to the product's robustness. The inductance measure is nominal at 25 degrees Celsius at 1KHz, reinforcing the coil's effective operation under different conditions.

I.T. Intertechnik Artikelnummer: 1340046
