Name: Intertechnik LU55/022/140 | 0,22 mH | 0,13 Ω | 3% | 15 AWG | Luftkernspule
Brand: Intertechnik
SKU: LU55/022/140
Price: 14.95 EUR
Availability: BackOrder

LU55/022/140 | 0,22 mH | 0,13 Ω | 3% | 15 AWG | Luftkernspule

12,36 €14,95 € Nicht auf Lager

Backorder

Wir versenden nach
Bald wieder auf Lager
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik LU55/022/140 | 0,22 mH | 0,13 Ω | 3% | 15 AWG

This is a high-quality Air Coil from I.T. Intertechnik with 0.22 mH inductance, 0.13 Ω resistance, and 3% tolerance.

Highlights

0.22 mH inductance for efficient signal transmission
0.13 Ω resistance for minimized power loss
3% tolerance for precise operations
Constructed with 15 AWG wire for durability

Product details

I.T. Intertechnik LU55/022/140 | 0,22 mH | 0,13 Ω | 3% | 15 AWG |Air Coil

This I.T. Intertechnik Air Coil is a top-of-the-line crossover component that offers 0.22 mH inductance and 0.13 Ω resistance, ensuring efficient signal transmission and minimal power loss. It has a tolerance of 3%, making it a precise and reliable component for any application. Manufactured with a 15 AWG wire, this coil is durable and built to last. The coil's wire is 99.99% pure, with a wire connection length of 10 mm and a tinning length of 9 mm. Its coil bobbin material is ABS, ensuring longevity and resilience. The coil's inductance value is measured nominally at 25 degrees C at 1KHz. With its high-quality construction and precise specifications, this air coil is an excellent choice for any high-performance crossover application.

I.T. Intertechnik Artikelnummer: 1340050
