Produktbeschreibung Intertechnik LU62/022/200 | 0,22 mH | 0,07 Ω | 3% | 12 AWG

This is a high-quality I.T. Intertechnik LU62/022/200 Air Coil, perfect for crossover components applications.

Highlights

Inductance value of 0.22 mH
Resistance of 0.07 Ω
3% Inductance tolerance
Constructed with 12 AWG wire

Product details

I.T. Intertechnik LU62/022/200 | 0,22 mH | 0,07 Ω | 3% | 12 AWG |Air Coil

I.T. Intertechnik's LU62/022/200 Air Coil is a standout in the field of crossover components air core coils. It features an inductance value of 0.22 mH and a resistance of 0.07 Ω, providing optimal performance for your audio systems. The coil comes with a 3% inductance tolerance, ensuring accurate and reliable functionality. Constructed with 12 AWG wire, this coil ensures excellent power handling and minimal power loss. The coil's wire has a 10mm length with a tin-plated length of 9mm, guaranteeing a secure and efficient connection. The coil's body is made from ABS material, providing it with excellent mechanical strength and durability. This product is measured at 25 degrees C at 1KHz, ensuring reliable performance across a wide range of temperatures and frequencies.

I.T. Intertechnik Artikelnummer: 1340908
