Name: Intertechnik LU92/5.6/140 | 5,6 mH | 0,83 Ω | 3% | 15 AWG | Luftkernspule
Brand: Intertechnik
SKU: LU92/5.6/140
Price: 63.25 EUR
Availability: InStock

LU92/5.6/140 | 5,6 mH | 0,83 Ω | 3% | 15 AWG | Luftkernspule

52,27 €63,25 € 2 Auf Lager

Wir versenden nach
Jetzt bestellt, heute versendet
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik LU92/5.6/140 | 5,6 mH | 0,83 Ω | 3% | 15 AWG

The I.T. Intertechnik LU92/5.6/140 is a high-quality air coil for crossover components.

Highlights

5.6 mH inductance
0.83 Ω resistance
3% capacitance tolerance
15 AWG wire gauge

Product details

I.T. Intertechnik LU92/5.6/140 | 5,6 mH | 0,83 Ω | 3% | 15 AWG |Air Coil

The I.T. Intertechnik LU92/5.6/140 is an air coil specifically designed for crossover components in audio systems. With an inductance of 5.6 mH and a resistance of 0.83 Ω, it is ideal for high-performance sound systems. The coil comes with a 3% capacitance tolerance and is constructed with a 15 AWG wire gauge, ensuring excellent audio quality. The wire connection length is 10mm, and the tin length is 9mm. The coil core material is ABS, which guarantees durability and longevity. The inductance value is measured at a nominal 25 degrees C at 1kHz, showing its effectiveness in a variety of temperature conditions. This product ensures accuracy and consistency, making it an excellent choice for your audio system needs.

I.T. Intertechnik Artikelnummer: 1340071
