Name: Intertechnik LUT32/022/10 | 0,22 mH | 0,26 Ω | 3% | 18 AWG | Air Therm Inductor
Brand: Intertechnik
SKU: LUT32/022/10
Price: 9.95 EUR
Availability: InStock

LUT32/022/10 | 0,22 mH | 0,26 Ω | 3% | 18 AWG | Air Therm Inductor

8,22 €9,95 € 4 Auf Lager

Wir versenden nach
Vor 16:00 Uhr bestellt, heute versandt
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik LUT32/022/10 | 0,22 mH | 0,26 Ω | 3% | 18 AWG

The I.T. Intertechnik LUT32/022/10 is a high-quality Air Therm Inductor, perfect for Crossover components Coils Air core coils applications.

Highlights

High-grade copper wire with thermal plastic insulation
Exceptional CU purity of over 99.99%
Inductance tolerance of -3% and resistance of 0.26 ohms
Resilient polycarbonate coil body material

Product details

I.T. Intertechnik LUT32/022/10 | 0,22 mH | 0,26 Ω | 3% | 18 AWG | Air Therm Inductor

This product, the I.T. Intertechnik LUT32/022/10, is a superior quality Air Therm Inductor designed for Crossover components Coils Air core coils applications. The inductor boasts a high-grade copper wire with thermal plastic insulation, ensuring optimal performance and durability. The CU purity is above 99.99%, and the wire connection length is 50 mm with a tinning length of 9 mm. The inductor features an inductance of 0.22 mH and a resistance of 0.26 ohms, with an inductance tolerance of -3%. The coil body material is made from resilient polycarbonate, capable of withstanding temperatures ranging from -90 to 135 degrees Celsius. The nominal L-value is measured at 25 degrees Celsius and 1 kHz. This inductor is the perfect choice for high-quality sound systems and other electronic devices.

I.T. Intertechnik Artikelnummer: 1340608
