      TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule

      Intertechnik TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule

      €312,45

      Nicht auf Lager

      Zum Warenkorb hinzufügen

      Intertechnik TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule

      0 reviews
      0 von 5
      0 reviews
      5 Sterne
      0%
      4 Sterne
      0%
      3 Sterne
      0%
      2 Sterne
      0%
      1 Stern
      0%
      Alle Bewertungen anzeigen
      Marke: Intertechnik
      Zeige alle Luftkernspulen
      TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule
      TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule
      TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule
      TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule
      312,45 € Nicht auf Lager
      +-
      Zum Warenkorb hinzufügen
      • Kostenloser Versand (DE & A)
      • Bald wieder auf Lager
      • Mindestens zwei Jahre Garantie
      • 45 Tage Widerrufsrecht
      • Kundenbewertung:
      Angebot anfordern
      TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule
      TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule
      TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule
      TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG | Tritec Spule

      Produktbeschreibung Intertechnik TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 7 x 23 AWG

      The I.T. Intertechnik TRI120/12.0/0.60 is a high-end, 12mH Tritec coil made for superior audio cabling.



      Highlights

      • High-end coils with "Septem Coxid" technology
      • Low ohmic resistances, extremely low skin effect
      • Constant inductance under voltage and load changes
      • Excellent sound quality due to reduced electromagnetic interference



      Product details

      I.T. Intertechnik TRI120/12.0/0.60 | 12 mH | 1,21 Ω | 1% | 23 AWG | Tritec Coil



      The I.T. Intertechnik TRI120/12.0/0.60 is a 12mH Tritec coil, specially designed for high-end audio cabling. It employs the unique "Septem Coxid" technology, featuring a concentric stranded design with seven individual strands. The coil is made from thermoplastic enamel wire, ensuring low ohmic resistances and an extremely low skin effect. It offers constant inductance under voltage and load changes, with virtually no saturation or hysteresis distortions. The coil also boasts a low self-capacitance, making it an excellent choice for high-quality sound. The copper purity is over 99.99%, and the wire has a length of 100 mm, with 10 mm of tinning. The coil body is made from polycarbonate, and the inductance tolerance is - 1%. The coil can withstand a temperature range of -90°C to 135°C, making it highly durable and reliable. With its seven-strand twisted conductor design, the coil offers increased flexibility, higher current carrying capacity, reduced skin effect, and noise reduction. This makes the Intertechnik Tritec coil a preferred choice in audio cabling.



      I.T. Intertechnik Artikelnummer: 1500247

      Eigenschaften

      Artikelnummer:
      TRI120/12.0/0.60
      EAN
      9505525493166
      Spulen-Typ
      Air core coils
      Induktion
      12 mH
      Gleichstromwiderstand
      1.21 ohms
      Toleranz
      1%
      Kabeldurchmesser
      23 AWG
