Name: Intertechnik TRI55/033/0.50 | 0,33 mH | 0,179 Ω | 1% | 24 AWG | Tritec Spule
Brand: Intertechnik
SKU: TRI55/033/0.50
Price: 34.25 EUR
Availability: InStock

TRI55/033/0.50 | 0,33 mH | 0,179 Ω | 1% | 24 AWG | Tritec Spule

28,31 €34,25 € 2 Auf Lager

Wir versenden nach
Vor 16:00 Uhr bestellt, heute versandt
Mindestens zwei Jahre Garantie
45 Tage Widerrufsrecht

Kundenbewertung:

Vergleichen

Angebot anfordern

Haben Sie eine Frage zu diesem Produkt?

Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

Produktbeschreibung Intertechnik TRI55/033/0.50 | 0,33 mH | 0,179 Ω | 1% | 24 AWG

A top-tier crossover component, the I.T. Intertechnik TRI55/033/0.50 Tritec Coil is designed for superior audio performance.

Highlights

High-end choke coil with "Septem Coxid" technology
Concentric litz construction with 7 individual strands
Constant inductance with voltage and load change
Excellent sound properties due to low self-capacitance

Product details

I.T. Intertechnik TRI55/033/0.50 | 0,33 mH | 0,179 Ω | 1% | 24 AWG | Tritec Coil

The I.T. Intertechnik TRI55/033/0.50 Tritec Coil is a high-end crossover component which combines all the desirable positive effects of a choke coil. This advanced product features "Septem Coxid" technology and a winding with a concentric litz construction of 7 individual strands. The coil offers very low ohmic resistances, no saturation distortions, and constant inductance, even with voltage and load changes. The low self-capacitance and excellent sound properties make it an exceptional choice for any audio setup. Its unique design, which includes a Tritec wire with 7 twisted strands, offers several advantages such as increased flexibility, higher current-carrying capacity, reduced skin effect, and noise reduction. The coil is made from polycarbonate with a purity of copper greater than 99.99%. The temperature coefficient is 0,000394 per degree C, and the insulation temperature is 150 degrees C. The wire connection length is 100mm with a tinning of 10mm.

I.T. Intertechnik Artikelnummer: 1500176
