        C173-6-096 7'' Bass-midwoofer

        Accuton C173-6-096 7'' Bass-midwoofer

        €999,95

        2 In stock

        Add to cart

        Accuton C173-6-096 7'' Bass-midwoofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Accuton
        Show all Bass-mid woofer
        7'' | 6 Ω
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        € 826,41€ 999,95 2 In stock
        • -5% Purchase 4 for only € 949,95 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer
        C173-6-096 7'' Bass-midwoofer

        Product description Accuton C173-6-096 Bass-midwoofer

        The Accuton C173-6-096 is a 7 inch high efficiency bass-midrange driver for 3-way designs. It features a large voice coil with a 55mm titanium voice coil former for high resolution in the midrange. Its large, 120mm neodymium magnet system provides very low distortion.



        Highlights

        • Underhung motor design
        • 55 mm Titanium VC Former
        • Soft Rubber Surround
        • Vented VC, Pole Piece & Spider
        • 40 HZ - 3 KHZ in vented Box



        Product details

        Accuton C173-6-096 7'' Bass-midwoofer



        This 7 inch bass-midrange with high efficiency for 3 way designs. Large sized voice coil with 55mm titanium voice coil former for high midrange resolution. Big, underhung 120mm Neodymium magnet system for very low distortion.



        The driver has an ultra-hard ceramic dome. Additionally, it has a power handling of 120 W, linear excursion of +/-5 mm, voice coil diameter of 55 mm, voice coil former material of titanium, voice coil material of copper, voice coil inductance of 0.31 mH, force factor of 11.35 N/A and motor type of underhung.

        Show more

        Specifications

        Article number
        C173-6-096
        EAN
        8785256847419
        Woofer Type
        Bass-midwoofer
        Nominal Diameter
        7"
        Power Handling (RMS)
        120W
        Sensitivity (SPL at 1m / 2.83V)
        93 dB
        DC Resistance (Re)
        6.77 Ohm
        Resonant Frequency (Fs)
        50 Hz
        Mechanical Q (Qms)
        4.68
        Electromagnetic Q (Qes)
        0.24
        Total Q (Qts)
        0.22
        Diaphragm Mass Inc. Airload (Mms)
        14.4 g
        Mechanical Compliance of Suspension (Cms)
        0.7 mm/n
        Surface Area of Cone (Sd)
        130 Cm2
        Compliance Equivalent Volume (Vas)
        16.99 ltr
        Maximum Linear Excursion (Xmax)
        5 mm
        Driver's Mechanical Losses (Rms)
        0.96 Kg's
        Cone / Diaphragm Material
        Ceramic
        Overall Outside Diameter
        173 MM
        Overall Depth
        102 MM
        Baffle Cutout Diameter
        146 MM

        Show more
