        C30-6-358 1,2'' Ceramic Cell Tweeter

        Accuton C30-6-358 1,2'' Ceramic Cell Tweeter

        €529,95

        8 In stock

        Add to cart

        Accuton C30-6-358 1,2'' Ceramic Cell Tweeter

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Accuton
        Show all Dome tweeter
        1.2" | 6 Ω
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        € 437,98€ 529,95 8 In stock
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Same day shipping
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter
        C30-6-358 1,2'' Ceramic Cell Tweeter

        Pros and cons

        According to our specialists
        • Full featured cell concept
        • Underhung motor design
        • No ferrofluid filling

        Product description Accuton C30-6-358 Cell Tweeter

        The C30-6-358 is a 1.2 inch tweeter with ultra hard ceramic dome in a 58 mm body. A proprietary clamping technique provides easy mounting and adapting to individual frontplates. As the dome breakup is above the audible range and well damped, no dome cutouts are required.



        Highlights

        • full featured cell concept
        • underhung motor design
        • vented vc & pole piece
        • no ferrofluid filling
        • 1800 HZ - 25000 HZ



        Product details

        Accuton C30-6-358 1,2'' Ceramic Cell Tweeter



        The Accuton C30-6-358 features an unique FEA optimized underhung motor design with vented titanium voice coil former and double neodymium magnet guarantees low energy storage, excellent heat transfer and high excursion capability for low power compression and ultra low distortion around 0.07% @ 2.83V and 0.5% max. @ 110dB. The new designed soft fabric surround centers the moving parts with improved linearity.



        The C30-6-358 is part of the Cell Concept series of drivers from Accuton. The Cell Concept is a unique approach to driver design that uses a series of small cells to create a large diaphragm area. This allows for greater control over the diaphragm movement and results in improved sound quality

        Show more

        Specifications

        Article number
        C30-6-358
        EAN
        8785256847501
        Tweeter Type
        Cell concept driver
        Tweeter Series
        C30
        Cone / Dome Diameter
        1.2" (30 mm)
        Power Handling (RMS)
        120 Watts
        Impedance (Z)
        6 Ω
        Sensitivity (SPL at 1m / 2.83V)
        93.5 dB
        Resonant Frequency (Fs)
        826 Hz
        DC Resistance (Re)
        5.8 Ω
        Voice Coil Inductance (Le)
        0.01 mH
        Mechanical Q (Qms)
        2.54
        Electromagnetic Q (Qes)
        0.81
        Total Q (Qts)
        0.62
        Overall Outside Diameter
        57.6 mm
        Cutout Diameter
        58 mm
        Depth
        28mm
        Diaphragm Material
        Ceramic
        Recommended cut frequency
        1800 Hz
