        PTMini-6 Planar Tweeter

        Dayton Audio PTMini-6 Planar Tweeter

        €14,95

        10+ In stock

        Add to cart

        Dayton Audio PTMini-6 Planar Tweeter

        17 reviews
        5 from 5
        17 reviews
        5 stars
        82%
        4 stars
        12%
        3 stars
        6%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Dayton Audio
        Show all Planar tweeter
        Planar | 6 Ω
        PTMini-6 Planar Tweeter
        PTMini-6 Planar Tweeter
        PTMini-6 Planar Tweeter
        PTMini-6 Planar Tweeter
        € 12,36€ 14,95 10+ In stock
        • -5% Purchase 4 for only € 14,20 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • Five-year warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        PTMini-6 Planar Tweeter
        PTMini-6 Planar Tweeter
        PTMini-6 Planar Tweeter
        PTMini-6 Planar Tweeter

        Product description Dayton Audio PTMini-6 Planar Tweeter

        The Dayton Audio PTMini-6 is a miniature planar tweeter that is big on performance and sound quality! With 6 ohm impedance and incredibly small size this is an excellent choice for car audio or home use.



        Highlights of the Dayton Audio PTMini-6 Planar Tweeter

        • Compact planar ribbon tweeter driver
        • High output and exceptional treble definition
        • Surface or flush mount installation
        • Potent neodymium magnetic design
        • Supports 4,000 Hz crossover, 12 dB/octave



        Product details Dayton Audio PTMini-6 Planar Tweeter

        Dayton Audio PTMini-6 Planar Tweeter 6 Ohm



        The clarity, definition, and transparency of a planar tweeter is unmatched by almost any other type of tweeter. Now Dayton Audio lets you build planar technology into more compact projects with the PTMini-6 planar tweeter! The surface-mount housing design can also be flush-mounted for a world of possible uses, such as a car A-pillar tweeter, a supertweeter for a full-range driver, a rear-mounted ambience tweeter, a conventional forward-facing tweeter configuration, or even a line array!



        The membrane of a planar tweeter is an almost weightless ribbon of heat-resistant Kapton material and an etched aluminum conductor, enabling the performance of aluminum ribbon tweeters without the losses inherent in the transformer of a conventional ribbon tweeter. The result is a tweeter that is incredibly fast, dynamic, and smooth sounding with imperceptible distortion and excellent power handling. A crossover cut-off frequency of 4,000 Hz or higher is recommended with a 12 dB/octave filter slope.



        FAQ about the Dayton Audio PTMini-6 Planar Tweeter

        What is the impedance of the PTMini-6?

        The Dayton Audio PTMini-6 typically has a nominal impedance of 6 ohms



        What are the characteristics of a planar tweeter?

        Planar tweeters have distinct characteristics that set them apart from conventional dome tweeters. Unlike dome tweeters, which use a small, domed diaphragm, planar tweeters feature a flat diaphragm, usually a very thin and lightweight film which also has responds quickly to high-frequency signals. Planar tweeters generally provide a broad and even sound dispersion and they are favored for their smooth, non-fatiguing sound. These characteristics make planar tweeters highly prized in high-end audio systems.

        Show more

        Specifications

        Article number
        PTMini-6
        EAN
        0848791001680
        Tweeter Type
        Planar ribbon tweeter
        Tweeter Series
        Planar Series
        Power Handling (RMS)
        15 Watts
        Impedance (Z)
        6 Ω
        Sensitivity (SPL at 1m / 2.83V)
        91.5 dB
        Frequency Response
        2,900 to 25,000 Hz
        Resonant Frequency (Fs)
        4461 Hz
        DC Resistance (Re)
        5.90 ohms
        Total Q (Qts)
        1.74
        Overall Outside Diameter
        3.27" x 0.91"
        Cutout Diameter
        Element: 2.375" x 0.375"
        Depth
        0.32"

        Show more

        Reviews

        17 reviews
        Review this product
        5 of 5
        Ein faszinierendes Bändchen zum Hammerpreis. Läuft bei mir als Unterstützung für die Kalottenhöchtöner (alte Hans Deutsch Regalboxen) ab 7khz/6db. Entgegen Erwartungen aller Art wurde ich super Überrascht, werden nicht die letzten sein die ich mir zugelegt habe. Für den Preis nen echter Schnapper.
        By PETER on 15 November 2024
        5 of 5
        -
        By Renan Vinicius on 7 July 2024
