        CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil

        Intertechnik CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil

        €18,95

        2 In stock

        Add to cart

        Intertechnik CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Intertechnik
        Show all Copper foil coils
        CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil
        CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil
        CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil
        CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil
        € 15,66€ 18,95 2 In stock
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil
        CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil
        CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil
        CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG | Tube Core Coil

        Product description Intertechnik CO44/120/050 | 12 mH | 3,87 Ω | 5% | 24 AWG

        The I.T. Intertechnik CO44/120/050 is a high-quality Tube Core Coil with a 12 mH inductance and 3.87 Ω resistance.



        Highlights

        • 12 mH inductance
        • 3.87 Ω resistance
        • 5% capacitance tolerance
        • Constructed with 24 AWG copper foil



        Product details

        I.T. Intertechnik CO44/120/050 | 12 mH | 3.87 Ω | 5% | 24 AWG | Tube Core Coil



        Belonging to the category of Crossover components Coils Copper foil coils, the I.T. Intertechnik CO44/120/050 Tube Core Coil has a distinct identity. The product boasts of a 12 mH inductance and a resistance of 3.87 Ω. The capacitance tolerance is set at 5%, indicating a stable and reliable performance. Made with 24 AWG copper foil, the coil ensures optimal conductivity. The copper purity is over 99.99% and the coil features a 10 mm wire connection length with a 9 mm tinning length. It uses ABS for spool body material and is built in either a Corobar or Ferrobar core shape. The inductance tolerance is kept at ± 5% and the inductance measurement is nominal at 25 degrees Celsius. This coil is a perfect choice for those looking for high performance and durability in their crossover components.



        I.T. Intertechnik article code: 1340978

        Show more

        Specifications

        Article number
        CO44/120/050
        EAN
        8785256850440
        Coil type
        Copper foil coils
        Inductance
        12 mH
        DCR
        3.87 ohms
        Tolerance
        5%
        Wire diameter
        24 AWG
        Dimensions: Ø * H (mm)
        44 x 28

        Show more
