        HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil

        Intertechnik HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil

        €8,45

        4 In stock

        Add to cart

        Intertechnik HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Intertechnik
        Show all Copper foil coils
        HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil
        HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil
        HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil
        HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil
        € 8,45 4 In stock
        +-
        Add to cart
        • We ship to United States of America
        • Ordered now, shipped tomorrow
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil
        HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil
        HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil
        HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil

        Product description Intertechnik HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG

        An Intertechnik HQR32/5.6/50 Tube Core Coil, perfect for crossover components with high copper purity.



        Highlights

        • High copper purity of over 99.99%
        • 5.6 mH inductance with a tolerance of ±5%
        • Resistance of 2.56 Ω
        • 24 AWG copper wire



        Product details

        I.T. Intertechnik HQR32/5.6/50 | 5,6 mH | 2,56 Ω | 5% | 24 AWG | Tube Core Coil



        The I.T. Intertechnik HQR32/5.6/50 Tube Core Coil is a top-quality addition to the realm of crossover components, particularly copper foil coils. This coil features an inductance of 5.6 mH and a resistance of 2.56 Ω, ensuring excellent performance. Its 24 AWG copper wire is made with a copper purity of over 99.99%, guaranteeing exceptional electrical conductivity and durability. The coil uses a Corobar or Ferrobar core form and has a wire connection length of 10 mm with a tinning length of 9 mm. The spool body is made from ABS, adding to its robustness. With a tolerance of ±5%, this coil delivers reliable results at a nominal 25 degrees C and 1 kHz. Trust the Intertechnik HQR32/5.6/50 for high precision and quality in your audio system.



        I.T. Intertechnik article code: 1340970

        Specifications

        Article number
        HQR32/5.6/50
        EAN
        8785256850402
        Coil type
        Copper foil coils
        Inductance
        5.6 mH
        DCR
        2.56 ohms
        Tolerance
        5%
        Wire diameter
        24 AWG

        Show more

        Reviews

        0 reviews
        Review this product

        There are no reviews written yet about this product..
