        000-2197 | 0,78 mH | 0,21 Ω | 3% | 18 AWG | Iron Core Coil

        Jantzen Audio 000-2197 | 0,78 mH | 0,21 Ω | 3% | 18 AWG | Iron Core Coil

        €5,25

        Out of stock

        Add to cart

        Jantzen Audio 000-2197 | 0,78 mH | 0,21 Ω | 3% | 18 AWG | Iron Core Coil

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Jantzen Audio
        Show all Iron core coils
        000-2197 | 0,78 mH | 0,21 Ω | 3% | 18 AWG | Iron Core Coil
        € 4,34€ 5,25 Out of stock
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        000-2197 | 0,78 mH | 0,21 Ω | 3% | 18 AWG | Iron Core Coil

        Product description Jantzen Audio 000-2197 | 0,78 mH | 0,21 Ω | 3% | 18 AWG

        Compact Jantzen Audio iron core coil with low resistance and high purity for crossovers.



        Highlights

        • 0.78 mH inductance with precision ±3% tolerance
        • Low 0.21 Ω DC resistance for minimal signal loss
        • High-quality 18 AWG high-purity copper wire
        • Non-ferrite Permite core for lower hysteresis



        Product details

        Jantzen Audio 000-2197 | 0,78 mH | 0,21 Ω | 3% | 18 AWG | Iron Core Coil



        The Jantzen Audio 000-2197 is an iron core coil specifically designed for the bass and mid sections of loudspeaker crossovers. With an inductance of 0.78 mH and a low DC resistance of only 0.21 Ω, this coil ensures minimal impact on driver damping factor and efficiency. The 18 AWG high-purity copper wire is meticulously wound around a Permite core to achieve an extremely low DCR and avoid loss of efficiency. Unlike coils with ferrite cores, the Permite material significantly reduces hysteresis, which translates into improved sound quality and power handling. The core size and wire thickness are optimized to handle power effectively, making this coil a reliable component for audio enthusiasts. With a tight inductance tolerance of ±3%, the Jantzen Audio 000-2197 promises consistent performance, making it an ideal choice for high-fidelity crossovers in premium audio systems.

        Show more

        Specifications

        Article number
        000-2197
        EAN
        9508932537829
        Coil type
        Iron core coils
        Inductance
        0.78 mH
        DCR
        0.21 ohms
        Tolerance
        3%
        Wire diameter
        18 AWG
        Dimensions: Ø * H (mm)
        26 x 30

        Show more
