        Classic MW265-8 Bass-midwoofer

        Morel Classic MW265-8 Bass-midwoofer

        €174,95

        Out of stock

        Add to cart

        Morel Classic MW265-8 Bass-midwoofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Morel
        Show all Bass-mid woofer
        8'' | 8 Ω
        Classic MW265-8 Bass-midwoofer
        Classic MW265-8 Bass-midwoofer
        Classic MW265-8 Bass-midwoofer
        Classic MW265-8 Bass-midwoofer
        € 144,59€ 174,95 Out of stock
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Classic MW265-8 Bass-midwoofer
        Classic MW265-8 Bass-midwoofer
        Classic MW265-8 Bass-midwoofer
        Classic MW265-8 Bass-midwoofer

        Product description Morel Classic MW265-8 Bass-midwoofer

        The Morel Classic MW265-8 is a 8-inch bass-midwoofer that is designed specifically for bass/midbass applications in IB enclosures. It features a high Qts design and a damped polymer cone that provides a full, extended response.



        Highlights

        • High Qts design
        • Works well in IB enclosures
        • Full, extended response
        • High power handling
        • Double ferrite magnet system
        • 75mm hexatech aluminum voice coil
        • Neoprene rubber surround
        • Vented rigid steel chassis
        • Minimal stray magnetic field
        • Shallow DPC cone



        Product details

        Morel Classic MW265-8 Bass-midwoofer



        The MW265-8 has a power handling of 1000W peak and a 75mm hexatech aluminum voice coil. It also features a neoprene rubber surround, a vented rigid steel chassis, and a minimal stray magnetic field. This bass-midwoofer is an excellent choice for larger 2-way or 3-way sealed systems.

        Show more

        Specifications

        Article number
        MW265-8
        EAN
        9509192659146
        Woofer Series
        Bass-Midrange
        Nominal Diameter
        8 Inch
        Power Handling (RMS)
        150 Watts
        Power Handling (max)
        1000 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        89 dB
        Frequency Response
        30 - 3.600 Hz
        Voice Coil Diameter
        75 mm
        DC Resistance (Re)
        5.20 Ω
        Voice Coil Inductance (Le)
        0.58 mH
        Resonant Frequency (Fs)
        30 Hz
        Mechanical Q (Qms)
        2.79
        Electromagnetic Q (Qes)
        0.79
        Total Q (Qts)
        0.61
        Diaphragm Mass Inc. Airload (Mms)
        25.5 gm
        Mechanical Compliance of Suspension (Cms)
        915 uM/N
        Surface Area of Cone (Sd)
        219 cm2
        BL Product (BL)
        0.72 T
        Compliance Equivalent Volume (Vas)
        61 Litres
        Maximum Linear Excursion (Xmax)
        +/- 3.5 mm
        Overall Outside Diameter
        222 mm
        Overall Depth
        69 mm
        Baffle Cutout Diameter
        214 mm
        # Mounting Holes
        8
        Mounting Hole Diameter
        4.2 mm
