        Supreme ST 1048 Dome Tweeter Matched Pair

        Morel Supreme ST 1048 Dome Tweeter Matched Pair

        €629,95

        Out of stock

        Add to cart

        Morel Supreme ST 1048 Dome Tweeter Matched Pair

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Morel
        Show all Morel tweeters
        1" | 8 Ω
        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair
        € 520,62€ 629,95 Out of stock
        • -5% Purchase 4 for only € 598,45 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair
        Supreme ST 1048 Dome Tweeter Matched Pair

        Product description Morel Supreme ST 1048 Dome Tweeter Matched Pair

        Innovative engineering and an advanced approach to acoustic construction are the reason for Supreme Series tweeters' superior high performance.



        Highlights

        • Sold in factory matched pairs
        • 104 mm IDR™ Improved Dispersion Recess aluminum faceplate
        • Flat neodymium motor structure provides maximum flux
        • Hexatech™ voice coil for maximum BL product and power handling
        • Acuflex™ coated dome with the perfect blend of internal damping and rigidity
        • Precisely matched acoustic loading between the dome cavity and rear chamber



        Product details

        Morel Supreme ST 1048 1" Dome Tweeter Matched Pair



        Innovative engineering and an advanced approach to acoustic construction are the reason for Supreme Series tweeters' superior high performance. Their underhung voice coils move in a significantly higher magnetic field and remain there always during operation. As a result, the Morel Supreme tweeters provide more linear excursion, eliminate intermodulation distortion, reduce power compression at high levels, and considerably improve low frequency reproduction.

        Show more

        Specifications

        Article number
        ST1048
        EAN
        0844632070792
        Tweeter Type
        Soft Dome
        Tweeter Series
        Supreme Series
        Cone / Dome Diameter
        25 mm | 1"
        Power Handling (RMS)
        220 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        91.5 dB
        Frequency Response
        1,400 to 22,000 Hz
        Resonant Frequency (Fs)
        680 Hz
        DC Resistance (Re)
        5.2 ohms
        Mechanical Q (Qms)
        0.8
        Electromagnetic Q (Qes)
        0.65
        Total Q (Qts)
        0.36
        Overall Outside Diameter
        4.09"
        Cutout Diameter
        2.95"
        Depth
        1.57"

        Show more
