        Ultimate UW1258 12" Subwoofer

        Morel Ultimate UW1258 12" Subwoofer

        €689,95

        2 In stock

        Add to cart

        Morel Ultimate UW1258 12" Subwoofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Morel
        Show all New products
        12" | 8 Ω
        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer
        € 570,21€ 689,95 2 In stock
        • -5% Purchase 4 for only € 655,45 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer
        Ultimate UW1258 12" Subwoofer

        Pros and cons

        According to our specialists
        • Massive power: 800w nominal, 3000w peak and 5.1" Large Hexatech™ Aluminum voice coil

        Product description Morel UW1258 Subwoofer

        And now…the Ultimate 12" subwoofer. Morel applied their years of experience and creative genius to produce a world-beating sub-bass driver. Extra-large diameter 5" voice coil, free-breathing cast frame, and symmetrical suspension system guarantee the ultimate in subwoofer performance.



        Highlights

        • Uniflow™ aluminum diecast chassis
        • High-flux double ferrite magnet system
        • 5.1" Hexatech™ aluminum voice coil with 1-1/2" winding length
        • Very high Xmax for extended bass response
        • One piece paper cone/center dome
        • Accucenter™ self-centering cone assembly
        • PFS™ Progression Field Symmetry spider/surround engineering



        Product details

        Morel Ultimate UW1258 12" Subwoofer



        The Morel UW1258 is a 12" subwoofer with one piece paper cone. It has a nominal impedance of 8 Ω, resonance frequency of 21 Hz, sensitivity of 87 dB and equivalent volume of 138 l. The total Q factor is 0.43 and the power is 800 W (DIN). It has a Uniflow Aluminum diecast chassis and a high flux double Ferrite magnet system.



        The Ultimate Subwoofer Line also includes other models such as the Classic Woofer which is a 10" paper/carbon cone with a nominal impedance of 4 Ω.

        Show more

        Specifications

        Article number
        UW1258
        EAN
        0844632070877
        Woofer Series
        Morel Ultimate Subwoofer series
        Woofer Type
        Ultimate Subwoofer
        Nominal Diameter
        305 mm, 12 Inch
        Power Handling (RMS)
        800 Watt
        Power Handling (max)
        3000 Watt
        Impedance (Z)
        8 Ohm
        Sensitivity (SPL at 1m / 2.83V)
        87 dB
        Voice Coil Diameter
        130 mm, 5.1 Inch
        DC Resistance (Re)
        6.8 Ohm
        Voice Coil Inductance (Le)
        1.33 mH
        Resonant Frequency (Fs)
        21 Hz
        Mechanical Q (Qms)
        1.88
        Electromagnetic Q (Qes)
        0.56
        Total Q (Qts)
        0.43
        Diaphragm Mass Inc. Airload (Mms)
        104.49 g
        Mechanical Compliance of Suspension (Cms)
        0.44 mm/N
        Surface Area of Cone (Sd)
        437 cm2
        BL Product (BL)
        0.64 T
        Compliance Equivalent Volume (Vas)
        138.38 Liters
        Maximum Linear Excursion (Xmax)
        12.5 mm
        Driver's Mechanical Losses (Rms)
        8.15 Kg/s
        Cone / Diaphragm Material
        Composite cellular fiber
        Voice Coil Wire Material
        Hexatech™ Aluminum
        Voice Coil Former
        Aluminum
        Basket / Frame Material
        Uniflow™ Aluminum
        # Mounting Holes
        6
        Mounting Hole Diameter
        6

        Show more
