        Product description Peerless by Tymphany HDS-P830860 Bass-midwoofer

        The Peerless High Definition Sound (HDS) Series offers high-quality solutions for multi-way speaker systems employing vented box alignments.



        Highlights

        • Truncated cast aluminum frame
        • PPB polypropylene cone with half-roll rubber surround
        • Long-throw voice coil
        • Shorting rings for reduced distortion
        • Under-spider and voice coil ventilation



        Product details



        Peerless by Tymphany 830860 5-1/4" PPB Cone HDS Woofer



        The Peerless High Definition Sound (HDS) Series offers high-quality solutions for multi-way speaker systems employing vented box alignments. A powerful ferrite magnet system is coupled to a finite element analysis-designed suspension system, containing a linear spider design and rubber surround. The motor incorporates an aluminum shorting ring that reduces coil inductance, extending frequency response performance and reducing second harmonic distortion. A cast aluminum basket provides high structural rigidity, heat-sinking capacity for the motor, and additional ventilation under the spider that in combination with a vented cone neck reduces air compression effects. Peerless developed the proprietary and highly advanced Polypropylene Black (PPB) cone material used in the HDS PPB Series, creating a stiff but still dampened cone that remains stable even under the greatest sound pressures.

        Show more

        Specifications

        Article number
        HDS-P830860
        EAN
        0844632084010
        Woofer Series
        Peerless by Tymphany HDS series
        Woofer Type
        Midwoofer
        Nominal Diameter
        5-1/4"
        Power Handling (RMS)
        30 Watts
        Power Handling (max)
        60 Watts
        Impedance (Z)
        8 Ohms
        Sensitivity (SPL at 1m / 2.83V)
        85.8 dB
        Frequency Response
        60 to 5,000 Hz
        Voice Coil Diameter
        1"
        DC Resistance (Re)
        5.9 ohms
        Voice Coil Inductance (Le)
        0.27 mH
        Resonant Frequency (Fs)
        62 Hz
        Mechanical Q (Qms)
        2.21
        Electromagnetic Q (Qes)
        0.59
        Total Q (Qts)
        0.47
        Diaphragm Mass Inc. Airload (Mms)
        9g
        Mechanical Compliance of Suspension (Cms)
        0.74 mm/N
        Surface Area of Cone (Sd)
        89.9 cm²
        BL Product (BL)
        5.9 Tm
        Compliance Equivalent Volume (Vas)
        0.3 ft.³
        Maximum Linear Excursion (Xmax)
        3.5 mm
        Cone / Diaphragm Material
        Poly
        Surround Material
        Rubber
        Basket / Frame Material
        Cast Aluminum
        Magnet Material
        Ferrite
        Overall Outside Diameter
        5.99"
        Overall Depth
        2.76"
        Baffle Cutout Diameter
        4.72"
        # Mounting Holes
        6
        Sealed Volume
        0.1 ft.³
        Sealed F3
        117 Hz
        Vented Volume
        0.31 ft.³
        Vented F3
        64 Hz

        Show more

        Reviews

        3 reviews
        Review this product
        5 of 5
        Klanglich ist nichts zu klagen. Angaben zu Schalldruck sind uneinheitlich und nicht mit früheren Produktspezifikationen vergleichbar. Voll geeignet als Ersatz für einen älteren Kalottenmitteltöner der einen deutlich höheren Schalldruck angab. Bohrung ist 12 cm, das findet sich nicht im Datenblatt. Die 51/4 Zoll betrifft wohl die abgeflachten Seiten und nicht den Kreisdurchmesser.
        By Dominikus on 26 November 2024
        5 of 5
        Very clear and dynamic midrange sound! Very high quality sound, even at high power. It has relative tight suspension and starts distortion at really high input power. It has a rising frequency response towards higher frequency, and requires proper crossover as any other driver, but Troles did a good job I think: I have built Troles Gravesen PPB-830860 kit with Peerless DX25 tweeter, and I am more than satisfied. I think it is a perfect driver fo...

        Show more

        By Benedek, Hungary on 16 September 2023
