        HDS-P830990 6-1/2" GFC Cone HDS Woofer

        Peerless by Tymphany HDS-P830990 6-1/2" GFC Cone HDS Woofer

        €69,95

        10+ expected on 06-12-2024

        Peerless by Tymphany HDS-P830990 6-1/2" GFC Cone HDS Woofer

        2 reviews
        5 from 5
        2 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        € 57,81€ 69,95 Out of stock10+ expected on 06-12-2024
        • -5% Purchase 4 for only € 66,45 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Pros and cons

        According to our specialists
        • Slim design (truncated cast frame)
        • Ideal for smaller baffles
        • Great frequency Response

        Product description Peerless by Tymphany HDS-P830990 Bass-midwoofer

        The Peerless High Definition Sound (HDS) Series offers high-quality solutions for multi-way speaker systems employing vented box alignments.



        Highlights of the Peerless HDS-P830990 Bass-midwoofer

        • Truncated cast aluminum frame
        • Glass-Fibre Composite (GFC) cone with half-roll rubber surround
        • Frequency Response 40 to 3,000Hz
        • Resonant Frequency (Fs): 46Hz
        • Shorting rings for reduced distortion
        • Under-spider and voice coil ventilation



        Product details Peerless HDS-P830990 Bass-midwoofer

        Peerless by Tymphany HDS-P830990 6-1/2" Bass midwoofer



        This 6.5 inch 8 ohm driver is a member of the high performance HDS family. A powerful ferrite magnet system is coupled to a finite element analysis designed suspension system, containing both a linear spider design and a rubber surround. The motor contains an aluminium shorting ring, which reduces coil inductance, thus providing both extended frequency response performance and reduced distortion. The long-throw voice coil ensures linear high excursion performance, needed for signal clarity. The cone necks are vented so as to reduce air compression effects under high excursion conditions. The cast aluminium basket offers structural rigidity, heat sinking capacity for the motor, and additional air venting under the spider so as to again reduce air compression effects. The cone in this model is a glass fibre composite, offering a unique visual and acoustic experience.



        FAQ about the Peerless HDS-P830990 Bass-midwoofer

        What makes the Peerless HDS-P830990 bass-midwoofer stand out in its category?

        The Peerless HDS-P830990 is known for its impressive combination of power handling, low distortion, and excellent midrange clarity. This 5.25-inch driver is part of the HDS line, which is designed for high-performance audio applications. Its fiberglass cone, phase plug, and die-cast aluminum basket contribute to a highly detailed, responsive sound, making it an excellent choice for high-end DIY speaker builds or as an upgrade in existing systems. It delivers a clean, linear response across the bass and midrange frequencies, handling crossover transitions smoothly.



        Can the HDS-P830990 be used in a two-way speaker setup?

        Absolutely. The HDS-P830990 is often used as the bass-midrange driver in two-way systems due to its excellent bandwidth and flat frequency response up to around 3 kHz, which makes it easy to integrate with a tweeter. Its low distortion and phase plug design also reduce breakup and maintain clarity at higher frequencies, simplifying crossover design and reducing the need for complex filtering.



        What effect does the fiberglass cone have on the performance of the HDS-P830990?

        The fiberglass cone strikes a balance between rigidity and lightness, allowing the driver to respond quickly without distorting. This results in tight, controlled bass and an open, natural midrange. Fiberglass is also relatively resistant to environmental factors like humidity, which helps ensure durability. Overall, the cone material contributes to the driver’s smooth frequency response and makes it a great option for applications requiring both accuracy and dynamic range.



        Can the HDS-P830990 be paired with other drivers in a multi-way system?

        Definitely. Its broad frequency response and low distortion make it versatile for use in two- or three-way systems. It can handle midrange and upper bass frequencies effectively, leaving room for a dedicated woofer to manage lower bass or a midrange driver to cover the higher frequencies in more complex setups. Many builders pair it with a high-quality dome or ribbon tweeter to create a balanced, full-range sound that performs well for both music and home theater applications.



        Peerless by Tymphany manufacturing code: T04-1B06B0002

        Show more

        Specifications

        Article number
        HDS-P830990
        EAN
        0844632084034
        Woofer Series
        Peerless by Tymphany HDS series
        Woofer Type
        Midwoofer
        Nominal Diameter
        6-1/2"
        Power Handling (RMS)
        50 Watts
        Power Handling (max)
        100 Watts
        Impedance (Z)
        8 Ohms
        Sensitivity (SPL at 1m / 2.83V)
        88.4 dB
        Frequency Response
        40 to 3,000Hz
        Voice Coil Diameter
        1.25"
        DC Resistance (Re)
        6.2 ohms
        Voice Coil Inductance (Le)
        0.42 mH
        Resonant Frequency (Fs)
        46 Hz
        Mechanical Q (Qms)
        3.1
        Electromagnetic Q (Qes)
        0.44
        Total Q (Qts)
        0.39
        Diaphragm Mass Inc. Airload (Mms)
        16.97g
        Mechanical Compliance of Suspension (Cms)
        0.7 mm/N
        Surface Area of Cone (Sd)
        143.1 cm²
        BL Product (BL)
        8.32 Tm
        Compliance Equivalent Volume (Vas)
        0.71 ft.³
        Maximum Linear Excursion (Xmax)
        5.34 mm
        Cone / Diaphragm Material
        Fiberglass
        Surround Material
        Rubber
        Basket / Frame Material
        Cast Aluminum
        Magnet Material
        Ferrite
        Overall Outside Diameter
        6.69"
        Overall Depth
        3.47"
        Baffle Cutout Diameter
        5.75"
        # Mounting Holes
        6
        Sealed Volume
        0.17 ft.³
        Sealed F3
        101 Hz
        Vented Volume
        0.5 ft.³
        Vented F3
        56 Hz

        Show more

        5 of 5
        Similarly as polypropylene HDS-P830874 version an outstanding midwoofer. The cone is a special paper/GF piston-like sandwich, a bit lighter with a tad higher sensitivity. AL shorting ring does its job especially at low frequencies below 200 Hz.
        By AR on 19 March 2023
        5 of 5
        Great quality and amazing sound
        By Wawe on 19 September 2019
