- Article number
- PLS-P830983
- EAN
- 0844632083822
- Woofer Series
- Peerless by Tymphany PLS series
- Woofer Type
- Full-Range
- Nominal Diameter
- 2"
- Power Handling (RMS)
- 7 Watts
- Power Handling (max)
- 14 Watts
- Impedance (Z)
- 4 ohms
- Sensitivity (SPL at 1m / 2.83V)
- 82.2 dB
- Frequency Response
- 150 to 20,000Hz
- Voice Coil Diameter
- 1"
- DC Resistance (Re)
- 3.6 ohms
- Voice Coil Inductance (Le)
- 0.03 mH
- Resonant Frequency (Fs)
- 176 Hz
- Mechanical Q (Qms)
- 5.6
- Electromagnetic Q (Qes)
- 0.81
- Total Q (Qts)
- 0.71
- Diaphragm Mass Inc. Airload (Mms)
- 1.6g
- Mechanical Compliance of Suspension (Cms)
- 0.5 mm/N
- Surface Area of Cone (Sd)
- 15.2 cm²
- BL Product (BL)
- 2.83 Tm
- Compliance Equivalent Volume (Vas)
- 0.01 ft.³
- Maximum Linear Excursion (Xmax)
- 1.65 mm
- Cone / Diaphragm Material
- Aluminum
- Surround Material
- Rubber
- Basket / Frame Material
- Polymer
- Magnet Material
- Neodymium
- Overall Outside Diameter
- 2.17"
- Overall Depth
- 1.38"
- Baffle Cutout Diameter
- 1.97"
- # Mounting Holes
- 4
- Sealed Volume
- 0.04 ft.³
- Sealed F3
- 199 Hz
- Vented Volume
- 0.03 ft.³
- Vented F3
- 108 Hz
