- Article number
- PLS-P830985
- EAN
- 0844632083860
- Woofer Series
- Peerless by Tymphany PLS series
- Woofer Type
- Full Range Woofer
- Nominal Diameter
- 2-1/2"
- Power Handling (RMS)
- 30 Watts
- Power Handling (max)
- 60 Watts
- Impedance (Z)
- 4 ohms
- Sensitivity (SPL at 1m / 2.83V)
- 86.5 dB
- Frequency Response
- 90 to 20,000Hz
- Voice Coil Diameter
- 1"
- DC Resistance (Re)
- 3.7 ohms
- Voice Coil Inductance (Le)
- 0.03 mH
- Resonant Frequency (Fs)
- 101.2 Hz
- Mechanical Q (Qms)
- 4.08
- Electromagnetic Q (Qes)
- 0.75
- Total Q (Qts)
- 0.63
- Diaphragm Mass Inc. Airload (Mms)
- 1.9g
- Mechanical Compliance of Suspension (Cms)
- 1.27 mm/N
- Surface Area of Cone (Sd)
- 22 cm²
- BL Product (BL)
- 2.7 Tm
- Compliance Equivalent Volume (Vas)
- 0.02 ft.³
- Maximum Linear Excursion (Xmax)
- 2 mm
- Cone / Diaphragm Material
- Aluminum
- Surround Material
- Rubber
- Basket / Frame Material
- Polymer
- Magnet Material
- Neodymium
- Overall Outside Diameter
- 2.75"
- Overall Depth
- 2.15"
- Baffle Cutout Diameter
- 2.42"
- # Mounting Holes
- 4
- Sealed Volume
- 0.1 ft.³
- Sealed F3
- 150 Hz
- Vented Volume
- 0.04 ft.³
- Vented F3
- 72 Hz
