- Article number
- PMT-2040N1625AL01-04
- EAN
- 9506791986680
- Woofer Series
- Peerless by Tymphany PMT series
- Woofer Type
- Full-range
- Nominal Diameter
- 1 x 2"
- Power Handling (RMS)
- 1 Watts
- Power Handling (max)
- 2 Watts
- Impedance (Z)
- 4Ω
- Sensitivity (SPL at 1m / 2.83V)
- 83.94 dB
- Frequency Response
- 200 to 20,000Hz
- Voice Coil Diameter
- 0.43"
- DC Resistance (Re)
- 3.97Ω
- Voice Coil Inductance (Le)
- 0.03mH
- Resonant Frequency (Fs)
- 339 Hz
- Mechanical Q (Qms)
- 2.73
- Electromagnetic Q (Qes)
- 2.44
- Total Q (Qts)
- 1.29
- Mechanical Compliance of Suspension (Cms)
- 0.61mm/N
- Surface Area of Cone (Sd)
- 7.4cm²
- BL Product (BL)
- 1.17T·m
- Compliance Equivalent Volume (Vas)
- 0.0017ft³
- Maximum Linear Excursion (Xmax)
- 0.4 mm
- Cone / Diaphragm Material
- Aluminum
- Surround Material
- Rubber
- Voice Coil Former
- Aluminum
- Basket / Frame Material
- Polymer
- Magnet Material
- Neodymium
- Overall Outside Diameter
- 1.08" x 1.67"
- Overall Depth
- 0.37"
- Baffle Cutout Diameter
- 1" x 1.59"
- Sealed Volume
- 0.01ft³
- Sealed F3
- 273.5Hz
