- Article number
- PMT-37N28AL01-04
- EAN
- 9506695765541
- Woofer Series
- Peerless by Tymphany PMT series
- Woofer Type
- Full-range
- Nominal Diameter
- 1-1/2"
- Power Handling (RMS)
- 5 Watts
- Power Handling (max)
- 10 Watts
- Impedance (Z)
- 4Ω
- Sensitivity (SPL at 1m / 2.83V)
- 84.25 dB
- Frequency Response
- 200 to 20,000Hz
- Voice Coil Diameter
- 1.1"
- DC Resistance (Re)
- 3.58Ω
- Voice Coil Inductance (Le)
- 0.06mH
- Resonant Frequency (Fs)
- 167.6 Hz
- Mechanical Q (Qms)
- 1.28
- Electromagnetic Q (Qes)
- 0.5
- Total Q (Qts)
- 0.36
- Mechanical Compliance of Suspension (Cms)
- 0.77mm/N
- Surface Area of Cone (Sd)
- 7.997cm²
- BL Product (BL)
- 3T·m
- Compliance Equivalent Volume (Vas)
- 0.00247ft³
- Maximum Linear Excursion (Xmax)
- 0.1 mm
- Cone / Diaphragm Material
- Aluminum
- Surround Material
- Rubber
- Voice Coil Former
- Aluminum
- Basket / Frame Material
- Polymer
- Magnet Material
- Neodymium
- Overall Outside Diameter
- 1.61"
- Overall Depth
- 0.465"
- Baffle Cutout Diameter
- 1.45"
- Vented Volume
- 0.01ft³
- Vented F3
- 131.6Hz
