- Article number
- SLS-P830668
- EAN
- 0844632084164
- Woofer Series
- Peerless by Tymphany SLS series
- Woofer Type
- Subwoofer
- Nominal Diameter
- 10"
- Power Handling (RMS)
- 70 Watts
- Power Handling (max)
- 140 Watts
- Impedance (Z)
- 8 ohms
- Sensitivity (SPL at 1m / 2.83V)
- 87.9 dB
- Frequency Response
- 30 to 2,000Hz
- Voice Coil Diameter
- 1.5"
- DC Resistance (Re)
- 5.6 ohms
- Voice Coil Inductance (Le)
- 1.37 mH
- Resonant Frequency (Fs)
- 32 Hz
- Mechanical Q (Qms)
- 7.1
- Electromagnetic Q (Qes)
- 0.59
- Total Q (Qts)
- 0.55
- Diaphragm Mass Inc. Airload (Mms)
- 56.28g
- Mechanical Compliance of Suspension (Cms)
- 0.43 mm/N
- Surface Area of Cone (Sd)
- 346.4 cm²
- BL Product (BL)
- 10.42 Tm
- Compliance Equivalent Volume (Vas)
- 2.57 ft.³
- Maximum Linear Excursion (Xmax)
- 8.3 mm
- Cone / Diaphragm Material
- Coated Paper
- Surround Material
- Rubber
- Basket / Frame Material
- Steel
- Magnet Material
- Ferrite
- Overall Outside Diameter
- 10"
- Overall Depth
- 5.24"
- Baffle Cutout Diameter
- 8.9"
- # Mounting Holes
- 8
- Sealed Volume
- 1.25 ft.³
- Sealed F3
- 56 Hz
- Vented Volume
- 3.92 ft.³
- Vented F3
- 28 Hz
