- Article number
- TC7FD00-04
- EAN
- 0844632092664
- Woofer Series
- Peerless by Tymphany TA, TC & TG series
- Woofer Type
- Full Range Woofer
- Nominal Diameter
- 2-1/2"
- Power Handling (RMS)
- 20 Watts
- Power Handling (max)
- 40 Watts
- Impedance (Z)
- 4 ohms
- Sensitivity (SPL at 1m / 2.83V)
- 82.4 dB
- Frequency Response
- 130 to 20,000Hz
- Voice Coil Diameter
- 0.75"
- DC Resistance (Re)
- 3.2 ohms
- Voice Coil Inductance (Le)
- 0.02 mH
- Resonant Frequency (Fs)
- 143 Hz
- Mechanical Q (Qms)
- 3.7
- Electromagnetic Q (Qes)
- 1.22
- Total Q (Qts)
- 0.92
- Diaphragm Mass Inc. Airload (Mms)
- 1.64g
- Mechanical Compliance of Suspension (Cms)
- 0.75 mm/N
- Surface Area of Cone (Sd)
- 22.1 cm²
- BL Product (BL)
- 1.97 Tm
- Compliance Equivalent Volume (Vas)
- 0.02 ft.³
- Maximum Linear Excursion (Xmax)
- 1 mm
- Cone / Diaphragm Material
- Paper
- Surround Material
- Rubber
- Basket / Frame Material
- Steel
- Magnet Material
- Ferrite
- Overall Outside Diameter
- 2.95"
- Overall Depth
- 1.43"
- Baffle Cutout Diameter
- 2.56"
- # Mounting Holes
- 4
- Sealed Volume
- 0.05 ft.³
- Sealed F3
- 138 Hz
- Vented Volume
- 0.1 ft.³
- Vented F3
- 82 Hz
