- Article number
- TC9FD18-08
- EAN
- 0844632083921
- Woofer Series
- Peerless by Tymphany TA, TC & TG series
- Woofer Type
- Full-range
- Nominal Diameter
- 3-1/2"
- Power Handling (RMS)
- 30 Watts
- Power Handling (max)
- 60 Watts
- Impedance (Z)
- 8 Ohms
- Sensitivity (SPL at 1m / 2.83V)
- 83.5 dB
- Frequency Response
- 100 to 20,000Hz
- Voice Coil Diameter
- 0.75"
- DC Resistance (Re)
- 6.3 ohms
- Voice Coil Inductance (Le)
- 0.05 mH
- Resonant Frequency (Fs)
- 125 Hz
- Mechanical Q (Qms)
- 2.7
- Electromagnetic Q (Qes)
- 1.33
- Total Q (Qts)
- 0.89
- Diaphragm Mass Inc. Airload (Mms)
- 2.43g
- Mechanical Compliance of Suspension (Cms)
- 0.67 mm/N
- Surface Area of Cone (Sd)
- 36.3 cm²
- BL Product (BL)
- 3.01 Tm
- Compliance Equivalent Volume (Vas)
- 0.04 ft.³
- Maximum Linear Excursion (Xmax)
- 2.55 mm
- Cone / Diaphragm Material
- Paper
- Surround Material
- Rubber
- Basket / Frame Material
- Polymer
- Magnet Material
- Ferrite
- Overall Outside Diameter
- Diagonal: 3.62", Across flats: 3.3"
- Overall Depth
- 1.69"
- Baffle Cutout Diameter
- 3"
- Bolt Circle Diameter
- 3.5"
- # Mounting Holes
- 4
- Sealed Volume
- 0.1 ft.³
- Sealed F3
- 122 Hz
- Vented Volume
- 0.2 ft.³
- Vented F3
- 72 Hz
