        SB12NRXF25-4 Norex Bass-midwoofer

        SB Acoustics SB12NRXF25-4 Norex Bass-midwoofer

        €62,45

        2 In stock

        SB Acoustics SB12NRXF25-4 Norex Bass-midwoofer

        1 reviews
        5 from 5
        1 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        € 51,61€ 62,45 2 In stock
        • -5% Purchase 4 for only € 59,33 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Pros and cons

        According to our specialists
        • Non-conducting fibre glass coil former for minimum damping
        • Reflex box : Not recommended

        Product description SB Acoustics SB12NRXF25-4 Bass-midwoofer

        The SB12NRXF25-4 is a 4-inch full-range driver from SB Acoustics. It features a proprietary cone material made from natural fibers, a foam surround, a vented cast aluminum chassis, and a CCAW voice coil. The driver has a nominal impedance of 4 ohms and a sensitivity of 87 dB. It is rated for a maximum power handling of 30 watts.



        Highlights

        • Proprietary cone material with natural fibres made in-house
        • Foam surround for maximum transparency and midrange resolution
        • Vented pole piece for reduced compression
        • Vented cast aluminium chassis for optimum strength and low compression
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires
        • Non-conducting fibre glass coil former for minimum damping
        • Shorting ring in motor system for reduced distortion



        Product details

        SB Acoustics SB12NRXF25-4 Norex Bass-midwoofer



        The SB12NRXF25-4 is a well-rounded 4-inch full-range driver that is capable of delivering clear, accurate sound in a variety of applications. It is a good choice for bookshelf speakers, satellite speakers, and subwoofers. The proprietary cone material is made from a blend of natural fibers that is said to provide a more natural and balanced sound than traditional paper cones.



        The foam surround is designed to provide a smooth and accurate response in the midrange frequencies. The vented cast aluminum chassis helps to dissipate heat and reduce distortion. The CCAW voice coil is lightweight and provides good power handling. The long life silver lead wires are resistant to corrosion and oxidation. The non-conducting fiberglass coil former helps to reduce noise and distortion. The shorting ring in the motor system helps to reduce distortion at high frequencies.

        Show more

        Specifications

        Article number
        SB12NRXF25-4
        EAN
        8785256847907
        Woofer Type
        Bass-midwoofer
        Nominal Diameter
        4 inch
        Power Handling (RMS)
        30 W
        Impedance (Z)
        4 Ω
        Sensitivity (SPL at 1m / 2.83V)
        87 dB
        Frequency Response
        100-2000 Hz
        Voice Coil Diameter
        25.4 mm
        Magnet Weight
        0.32 kg
        DC Resistance (Re)
        3.1 Ω
        Voice Coil Inductance (Le)
        0.27 mH
        Resonant Frequency (Fs)
        61 Hz
        Mechanical Q (Qms)
        5.3
        Electromagnetic Q (Qes)
        0.53
        Total Q (Qts)
        0.48
        Diaphragm Mass Inc. Airload (Mms)
        5.8 g
        Compliance Equivalent Volume (Vas)
        4.1
        Driver's Mechanical Losses (Rms)
        0.42 kg/s
        Overall Outside Diameter
        123 mm
        Overall Depth
        69.8 mm
        # Mounting Holes
        4
        Mounting Hole Diameter
        4,3 mm

        Show more
