        Product description SB Acoustics SB17NRX2C35-4 Bass-midwoofer

        The SB Acoustics SB17NRX2C35-4 is a 6.5'' (171mm) bass-midwoofer that has a nominal impedance of 4 Ω and a voice coil diameter of 35.5 mm. It has an effective piston area of 118 cm² and a voice coil height of 16 mm. The speaker has a free air resonance of 36 Hz and a sensitivity of 90 dB (2.83V/1m).



        Highlights

        • Vented cast aluminum chassis for optimum strength and low compression
        • Proprietary cone material with natural fibers made in-house
        • Soft low damping rubber surround for transient response
        • Non-conducting fiber glass voice coil former for minimum damping
        • Extended copper sleeve on pole piece for low inductance and low distortion
        • Vented coil former
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires
        • Vented pole piece for reduced compression



        Product details

        SB Acoustics SB17NRX2C35-4 Norex Bass-midwoofer



        The SB17NRX2C35-4 is made with a proprietary cone material that is made in-house, and it has a soft low damping rubber surround for transient response. The voice coil former is made of non-conducting fiberglass, and the pole piece has an extended copper sleeve for low inductance and low distortion. The woofer also has a vented coil former and CCAW voice coil for reduced moving mass. It has a rated power handling of 60 W. The woofer has a vented cast aluminum chassis for optimum strength and low compression and a proprietary cone material with natural fibers made in-house.

        Show more

        Specifications

        Article number
        SB17NRX2C35-4
        EAN
        8785256848041
        Woofer Series
        SB Acoustics NRX Norex series
        Nominal Diameter
        171 mm
        Power Handling (RMS)
        60 Watt
        Power Handling (max)
        120 Watt
        Impedance (Z)
        4 Ohm
        Sensitivity (SPL at 1m / 2.83V)
        90 dB
        Frequency Response
        100-3000 Hz
        Voice Coil Diameter
        35.5 mm
        Magnet Weight
        0.54 kg
        DC Resistance (Re)
        3.1 Ohm
        Voice Coil Inductance (Le)
        0.13 mH
        Resonant Frequency (Fs)
        36 Hz
        Mechanical Q (Qms)
        4.49
        Electromagnetic Q (Qes)
        0.41
        Total Q (Qts)
        0.37
        Diaphragm Mass Inc. Airload (Mms)
        13.9 g
        Volume of Displacement (Vd)
        118 cm2
        BL Product (BL)
        4.9 Tm
        Compliance Equivalent Volume (Vas)
        27.6 liters
        Driver's Mechanical Losses (Rms)
        0.7 kg/s
        Overall Outside Diameter
        171 mm
        Overall Depth
        85.9 mm
        # Mounting Holes
        4
        Mounting Hole Diameter
        4.3 mm
