        SB21RDC-C000-4 Ring Dome Tweeter

        SB Acoustics SB21RDC-C000-4 Ring Dome Tweeter

        €49,95

        10+ In stock

        Add to cart

        SB Acoustics SB21RDC-C000-4 Ring Dome Tweeter

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SB Acoustics
        Show all SB Acoustics tweeters
        3/4" | 4 Ω
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        € 41,28€ 49,95 10+ In stock
        • -5% Purchase 4 for only € 47,45 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter
        SB21RDC-C000-4 Ring Dome Tweeter

        Product description SB Acoustics SB21RDC-C000-4 Ring Dome Tweeter

        Highlights

        •  Non-resonant diaphragm design for minimum high frequency break-up
        •  Dual balanced compression chamber for improved dynamics
        •  Copper cap for reduced voice coil inductance and minimum phase shift
        •  Saturation controlled motor system for low distortion
        •  Non-reflective rear chamber with optimized damping for improved dynamics
        •  Flow optimized vented pole piece for optimum coupling to rear chamber
        •  CCAW voice coil for low moving mass
        •  Long life silver lead wires
        •  Low resonance frequency



        Product details

        SB Acoustics SB21RDC-C000-4 3/4" Ring Tweeter



        Non-resonant diaphragm design for minimum high frequency break-up and dual balanced compression chamber for improved dynamics. Copper cap for reduced voice coil inductance and minimum phase shift. Saturation controlled motor system for low distortion. Non-reflective rear chamber with optimized damping for improved dynamics. Flow optimized vented pole piece for optimum coupling to rear chamber. CCAW voice coil for low moving mass. Long life silver lead wires and low resonance frequency.



        Specifications: BL Product (BL): 1.5 Tm N • Diaphragm Mass Inc. Airload (Mms): 0.25 g • Maximum Linear Excursion (Xmax): 0.5 mm • Surface Area of Cone (Sd): 4.6 cm2

        Show more

        Specifications

        Article number
        SB21RDC-C000-4
        EAN
        0696277268948
        Tweeter Type
        Ring Radiator
        Cone / Dome Diameter
        20 mm | 4/5"
        Power Handling (RMS)
        40 Watts
        Impedance (Z)
        4 Ω
        Sensitivity (SPL at 1m / 2.83V)
        90 dB
        Resonant Frequency (Fs)
        760 Hz
        DC Resistance (Re)
        3.1 ohms
        Voice Coil Inductance (Le)
        0.04 mH
        Mechanical Q (Qms)
        2.54
        Electromagnetic Q (Qes)
        1.64
        Total Q (Qts)
        1.00

        Show more
