        SB23CACS45-4 Woofer

        SB Acoustics SB23CACS45-4 Woofer

        €151,95

        3 In stock

        Add to cart

        SB Acoustics SB23CACS45-4 Woofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SB Acoustics
        Show all Bass-mid woofer
        8'' | 4 Ω
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        € 125,58€ 151,95 3 In stock
        • -5% Purchase 4 for only € 144,35 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer
        SB23CACS45-4 Woofer

        Product description SB Acoustics SB23CACS45-4 Woofer

        Highlights

        • Soft low damping rubber surround for improved transient response
        • Geometrically reinforced ceramic cone for improved break-up control
        • Shorting ring in motor system for reduced distortion
        • Vented pole piece for reduced compression
        • Vented cast aluminium chassis for optimum strength and low compression
        • Shallow design
        • Non-conducting fibre glass voice coil former for minimum damping
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires
        • Shallow design



        Product details

        SB Acoustics SB23CACS45-4 Woofer



        The SB Acoustics SB23CACS45-4 is a 8 inch 4 ohm woofer / bass speaker featuring a geometrically reinforced ceramic cone, a low distortion motor system and a vented cast aluminium chassis. The ceramic layer is bonded to an aluminium substrate, this combination of materials results in an excellent stiffness to damping ratio. A very low distortion design for applications with restricted rear depth.



        Show more

        Specifications

        Article number
        SB23CACS45-4
        EAN
        8785256845446
        Nominal Diameter
        234 mm
        Power Handling (RMS)
        60 Watt
        Impedance (Z)
        4 Ohm
        Sensitivity (SPL at 1m / 2.83V)
        90 dB
        Voice Coil Diameter
        46 mm
        DC Resistance (Re)
        3.3 Ohm
        Voice Coil Inductance (Le)
        0.27 mH
        Resonant Frequency (Fs)
        23 Hz
        Mechanical Q (Qms)
        6.00
        Electromagnetic Q (Qes)
        0.35
        Total Q (Qts)
        0.33
        Diaphragm Mass Inc. Airload (Mms)
        33 g
        Moving Mass Of Diaphragm (Mmd)
        30.7 g
        Mechanical Compliance of Suspension (Cms)
        1430 µm/N
        Surface Area of Cone (Sd)
        216 cm2
        Volume of Displacement (Vd)
        140 cm3
        BL Product (BL)
        6.7 N/A
        Compliance Equivalent Volume (Vas)
        95 Liters
        Maximum Linear Excursion (Xmax)
        6.5 mm
        Driver's Mechanical Losses (Rms)
        0.8 N·s/m
        Overall Outside Diameter
        234 mm
        Overall Depth
        92.4 mm
        Baffle Cutout Diameter
        205 mm
        # Mounting Holes
        8
        Mounting Hole Diameter
        4.3 mm

        Show more
