        SB29RDC-C000-4 Ring Dome Tweeter

        SB Acoustics SB29RDC-C000-4 Ring Dome Tweeter

        €53,45

        7 In stock7 expected on 26-12-2024

        Add to cart

        SB Acoustics SB29RDC-C000-4 Ring Dome Tweeter

        1 reviews
        5 from 5
        1 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SB Acoustics
        Show all SB Acoustics tweeters
        1⅛" | 4 Ω
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        € 44,17€ 53,45 7 In stock7 expected on 26-12-2024
        • -5% Purchase 4 for only € 50,78 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter
        SB29RDC-C000-4 Ring Dome Tweeter

        Product description SB Acoustics SB29RDC-C000-4 Ring Dome Tweeter

        Highlights

        • Non-resonant diaphragm design for minimum high frequency break-up
        • Dual balanced compression chamber for improved dynamics
        • Copper cap for reduced voice coil inductance and minimum phase shift
        • Saturation controlled motor system for low distortion
        • Non-reflective rear chamber with optimized damping for improved dynamics
        • Flow optimized vented pole piece for optimum coupling to rear chamber
        • CCAW voice coil for low moving mass
        • Long life silver lead wires
        • Low resonance frequency
        • The larger terminal is the positive



        Product details

        SB Acoustics SB29RDC-C000-4 Ring Dome Tweeter



        This tweeter features a proprietary fabric ring dome with a large roll surround. Stabilizing the center of the dome greatly reduces distortion and brings the acoustic center of the tweeter back to the voice coil, with the added benefit of increased sensitivity. The tweeter has a chambered back designed to provide a lower resonance frequency and reduce back wave reflections from the dome. A copper cap is used on the pole piece. Large surface area.



        Specifications: Diaphragm Mass Inc. Airload (Mms): 0.45 g • Maximum Linear Excursion (Xmax): 0.25 mm • Surface Area of Cone (Sd): 9.6 cm2

        Show more

        Specifications

        Article number
        SB29RDC-C000-4
        EAN
        0696277268962
        Tweeter Type
        Dome
        Cone / Dome Diameter
        25 mm | 1"
        Power Handling (RMS)
        100 Watts
        Impedance (Z)
        4 Ω
        Sensitivity (SPL at 1m / 2.83V)
        93 dB
        Resonant Frequency (Fs)
        600 Hz
        DC Resistance (Re)
        3 ohms
        Voice Coil Inductance (Le)
        0.05 mH
        Mechanical Q (Qms)
        2.2
        Electromagnetic Q (Qes)
        0.9
        Total Q (Qts)
        0.65

        Show more

        Reviews

        1 reviews
        Review this product
        5 of 5
        very good tanks
        By Luca C. on 3 October 2018
