        Satori TW29B Dome Tweeter

        SB Acoustics Satori TW29B Dome Tweeter

        €334,95

        4 In stock

        Add to cart

        SB Acoustics Satori TW29B Dome Tweeter

        1 reviews
        5 from 5
        1 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SB Acoustics
        Show all SB Acoustics tweeters
        1⅛" | 4 Ω
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        € 276,82€ 334,95 4 In stock
        • -5% Purchase 4 for only € 318,20 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter
        Satori TW29B Dome Tweeter

        Product description SB Acoustics Satori TW29B Dome Tweeter

        Highlights

        • Beryllium dome for non-resonant high frequency extension
        • Two part aluminum faceplate with integrated mechanical decoupling
        • Dual balanced compression chambers for improved dynamics
        • Dual copper caps for absolute minimum voice coil inductance and minimum phase shift
        • Non-reflective cast aluminum chamber with optimized damping for improved dynamics
        • Shallow flow optimized magnet structure for optimum coupling to rear chamber
        • CCAW voice coil for low moving mass
        • Long life silver lead wires
        • Low resonance frequency for extended range



        Product details

        SB Acoustics Satori TW29B Beryllium Dome Tweeter



        The new Satori Beryllium dome tweeter with ferrite magnet has arrived!  Beryllium is known for its open and spatial sound, often described as holographic.  The self-damping properties of Beryllium allow for an extended response without a huge spike in the response at higher frequencies seen in most metal dome tweeters.  All dome materials have a different tonal and spatial presentation.  Beryllium has a real positive difference, providing an experience unlike all other dome materials.  This new ferrite magnet version has a little less output for a very competitive price.



        Specifications: BL Product (BL): 2 Tm N • Diaphragm Mass Inc. Airload (Mms): 0.46 g • Maximum Linear Excursion (Xmax): 0.25 mm • Surface Area of Cone (Sd): 9.6 cm2

        Show more

        Specifications

        Article number
        TW29B
        EAN
        0696277268856
        Tweeter Type
        Dome
        Tweeter Series
        Satori Series
        Cone / Dome Diameter
        25 mm | 1"
        Power Handling (RMS)
        80 Watts
        Impedance (Z)
        4 Ω
        Sensitivity (SPL at 1m / 2.83V)
        92 dB
        Resonant Frequency (Fs)
        600 Hz
        DC Resistance (Re)
        3 ohms
        Voice Coil Inductance (Le)
        0.02 mH
        Mechanical Q (Qms)
        2.9
        Electromagnetic Q (Qes)
        1.3
        Total Q (Qts)
        0.90

        Show more

        Reviews

        1 reviews
        Review this product
        5 of 5
        it is unbelievable how this tweeter improves resolution and impulse response.
        By Rainer on 5 July 2019
