        Gold Series 16W/4538G05 Car Mid-range Woofer

        Scan-Speak Gold Series 16W/4538G05 Car Mid-range Woofer

        €499,95

        4 In stock

        Add to cart

        Scan-Speak Gold Series 16W/4538G05 Car Mid-range Woofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Scan-Speak
        Show all Scan-Speak woofers
        6
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        € 413,18€ 499,95 4 In stock
        • -5% Purchase 4 for only € 474,95 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer
        Gold Series 16W/4538G05 Car Mid-range Woofer

        Product description Scan-Speak Gold Series 16W/4538G05 Woofer

        Our GOLD SERIES are specially selected units from Scan-Speak’s well-known home audio speakers. Which have been optimized for automotive use. This series enables audiophiles to experience in their vehicle the – TRUE TO LIVE – that they enjoy from their high-end home audio system.



        Highlights

        • Die Cast Housing & Face Plate
        • High Grade Compact Neo magnet System
        • Low Damping SBR Rubber Surround
        • Low-Loss linear suspension
        • Patented Symmetrical Drive Motor Design
        • Robust Die cast Alu Chassis



        Product details

        Scan-Speak Gold Series 16W/4538G05 Car Mid-range Woofer



        The Scan-Speak Gold Series 16W/4538G05 is a high-end 6.5" woofer that is designed for automotive use. It features a number of innovative technologies that make it capable of delivering outstanding sound quality.



        One of the most notable features is its sandwich cone. This cone is made up of a sliced paper membrane that is bonded to a rearside polycarbonate membrane. This unique construction provides the cone with a high degree of rigidity and damping, which helps to suppress cone breakup modes and improve overall sound quality.



        The 16W/4538G05 also features a symmetrical drive motor system. This system uses a pair of magnets that are arranged symmetrically around the voice coil. This helps to improve the woofer's linearity and reduce distortion.



        The Woofer is also equipped with a low-damping SBR rubber surround. This surround provides the woofer with a smooth, linear response and helps to reduce distortion. It's finished in a black anodized aluminium chassis. This chassis is both lightweight and strong, and it helps to protect the woofer from damage.

        Show more

        Specifications

        Article number
        16W/4538G05
        EAN
        8785256848287
        Woofer Type
        Automotive
        Nominal Diameter
        160 mm
        Power Handling (RMS)
        70 Watt
        Power Handling (max)
        125 Watt
        Impedance (Z)
        4 Ohm
        Sensitivity (SPL at 1m / 2.83V)
        90 dB
        Frequency Response
        36-5000 Hz
        Voice Coil Diameter
        38 mm
        DC Resistance (Re)
        3.1 Ohm
        Voice Coil Inductance (Le)
        0.18 mH
        Resonant Frequency (Fs)
        36 Hz
        Mechanical Q (Qms)
        3.82
        Electromagnetic Q (Qes)
        0.39
        Total Q (Qts)
        0.35
        Diaphragm Mass Inc. Airload (Mms)
        16.9 g
        Mechanical Compliance of Suspension (Cms)
        1.12 mm/N
        Surface Area of Cone (Sd)
        123 cm2
        BL Product (BL)
        5.5 Tm
        Compliance Equivalent Volume (Vas)
        24 Litres
        Maximum Linear Excursion (Xmax)
        13.5 mm
        Driver's Mechanical Losses (Rms)
        1 kg/s
        Overall Outside Diameter
        165 mm
        Baffle Cutout Diameter
        141 mm
        # Mounting Holes
        5
        Mounting Hole Diameter
        5.2 mm
        Vented Volume
        21 Litres

        Show more
