        Revelator 22W/8857T00 Bass-mid woofer

        Scan-Speak Revelator 22W/8857T00 Bass-mid woofer

        €339,95

        6 In stock

        Scan-Speak Revelator 22W/8857T00 Bass-mid woofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Scan-Speak
        € 280,95€ 339,95 6 In stock
        • -5% Purchase 4 for only € 322,95 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description Scan-Speak Revelator 22W/8857T00 Bass-mid woofer

        Highlights

        • Patented Symmetrical Drive Motor Design
        • Rigid Black Anodized Alu Cone
        • Low-Loss linear suspension
        • Low Damping SBR Rubber Surround
        • Die cast Alu Chassis vented below spider
        • Ferrite Magnet System w. Rubber Boot



        Product details

        Scan-Speak 22W/8857T00 Bass-mid woofer



        The Revelator woofers and subwoofers features very rigid cones in paper or aluminium that operates as a piston over a wide frequency range, in combination with Scan-Speaks low-loss linear suspension and the patented Symmetrical Drive (SD-1) it results in very low distortion and a smooth and well behaved frequency response as well as perfect transient reproduction.

        Show more

        Specifications

        Article number
        22W/8857T00
        EAN
        8785256845712
        Woofer Series
        Scan-Speak Revelator series
        Woofer Type
        Bass-mid woofer
        Nominal Diameter
        8.5"
        Power Handling (RMS)
        80 Watts
        Power Handling (max)
        200 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        86 dB
        DC Resistance (Re)
        6.2 Ω
        Resonant Frequency (Fs)
        23 Hz
        Total Q (Qts)
        0.3
        Surface Area of Cone (Sd)
        220 cm²
        BL Product (BL)
        10.1 Tm
        Compliance Equivalent Volume (Vas)
        87.7 ltr.
        Maximum Linear Excursion (Xmax)
        4.5 mm

        Show more
