        Revelator D2904/710002 Dome Tweeter

        Scan-Speak Revelator D2904/710002 Dome Tweeter

        €319,95

        4 In stock

        Add to cart

        Scan-Speak Revelator D2904/710002 Dome Tweeter

        1 reviews
        5 from 5
        1 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Scan-Speak
        Show all Scan-Speak tweeters
        1" | 4 Ω
        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter
        € 264,42€ 319,95 4 In stock
        • -5% Purchase 4 for only € 303,95 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter
        Revelator D2904/710002 Dome Tweeter

        Product description Scan-Speak Revelator D2904/710002 Dome Tweeter

        Highlights

        • 1" Coated Textile Diaphragm
        • Patented Symmetrical Drive (SD-2) motor
        • Non Resonant Alu Rear Chamber
        • Large Roll Surround for Wide Dispersion
        • Large Ring Neo Magnet for High Output
        • Silver Anodized Machined Alu Face Plate



        Product details

        Scan-Speak Revelator D2904/710002 1" Coated Textile Dome Tweeter



        The Scan-speak D2904-710002 tweeter is a 1" soft dome with wide surround, using the same chambering as the Ring Radiator.



        The carefully designed dome and surround result in a linear response and an exceptionally good off axis response. Note the smooth roll off on the low end, making this tweeter an excellent choice for simple slopes. A specially designed venting system uses a needle to cut down on turbulence in the air cavity. Better dynamics are achieved by not using ferrofluid, voice coil cooling is performed by the venting system and conduction through copper rings. The new SD-2 neodymium magnet system improves transient response.



        Specifications: Compliance Equivalent Volume (Vas): 0.0007 ft.³ • BL Product (BL): 2.8 Tm • Mechanical Compliance of Suspension (Cms): 0.23 mm/N • Diaphragm Mass Inc. Airload (Mms): 0.4 g • Maximum Linear Excursion (Xmax): 0.2 mm • Surface Area of Cone (Sd): 7 cm2

        Show more

        Specifications

        Article number
        D2904/710002
        EAN
        0696277268450
        Tweeter Type
        Dome
        Tweeter Series
        Revelator Series
        Cone / Dome Diameter
        25 mm | 1"
        Power Handling (RMS)
        90 Watts
        Power Handling (max)
        150 Watts
        Impedance (Z)
        4 Ω
        Sensitivity (SPL at 1m / 2.83V)
        94.4 dB
        Resonant Frequency (Fs)
        520 Hz
        DC Resistance (Re)
        3 ohms
        Voice Coil Inductance (Le)
        0.01 mH
        Mechanical Q (Qms)
        3.50
        Electromagnetic Q (Qes)
        0.50
        Total Q (Qts)
        0.44

        Show more

        Reviews

        1 reviews
        Review this product
        5 of 5
        -
        By Artem on 23 April 2024
        Revelator D2904/710002 Dome Tweeter
        € 264,42
        € 319,95
        Revelator D2904/710002 Dome Tweeter
        D2904/710002
        4 In stock
        Add to cart
