        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm

        Scan-Speak PL14WJ09-08 5'' Bass-midwoofer 8 Ohm

        €84,95

        Out of stock

        Add to cart

        Scan-Speak PL14WJ09-08 5'' Bass-midwoofer 8 Ohm

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Scan-Speak
        Show all New products
        5" | 8 Ω
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        € 70,21€ 84,95 Out of stock
        • -5% Purchase 4 for only € 80,70 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm
        PL14WJ09-08 5'' Bass-midwoofer 8 Ohm

        Product description Scan-Speak PL14WJ09-08 Mid-range Woofer

        A 5" NRSC coated cone with wide profile low rubber surround has outstanding smooth extended bass response, famously flat frequency response, smooth roll-off, all powered by a huge magnet assembly.



        Highlights

        • power handling (continuous/programme) = 200/250 W
        • Smooth and extended bass response
        • Large magnet assembly for good power handling and efficiency
        • NRSC coated paper cone with wide profile low rubber surround
        • Easy to find second-hand drivers



        Product details

        Scan-Speak PL14WJ09-08 5'' Bass-midwoofer 8 Ohm



        The PL14WJ09-08 is a 5-inch mid-woofer speaker driver that was manufactured by Vifa (now Scanspeak). It was discontinued in 2012, but it is still a popular choice for DIY speakers due to its smooth sound and extended bass response.



        The PL14WJ09-08 has a number of features that make it a good choice for mid-range applications. It has a NRSC coated paper cone with a wide profile low rubber surround. This gives the driver a smooth and extended bass response, with a cutoff frequency of around 50 Hz. The driver also has a large magnet assembly, which gives it good power handling and efficiency.



        The PL14WJ09-08 is not particularly efficient, with a sensitivity of 86 dB (2.83V; 1m). However, this can be compensated for by using a larger cabinet or by pairing the driver with a more efficient tweeter.

        Show more

        Specifications

        Article number
        PL14WJ09-08
        EAN
        8785256847853
        Nominal Diameter
        5 "
        Power Handling (RMS)
        200 Watt
        Power Handling (max)
        250 Watt
        Impedance (Z)
        8 Ohm
        Sensitivity (SPL at 1m / 2.83V)
        86 dB
        Voice Coil Diameter
        32 mm
        Magnet Weight
        0.415 kg
        DC Resistance (Re)
        5.8 Ohm
        Voice Coil Inductance (Le)
        0.49 mH
        Resonant Frequency (Fs)
        47 Hz
        Mechanical Q (Qms)
        2.2
        Electromagnetic Q (Qes)
        0.46
        Total Q (Qts)
        0.38
        Diaphragm Mass Inc. Airload (Mms)
        8.2 g
        Surface Area of Cone (Sd)
        80 cm2
        BL Product (BL)
        5.5 Tm
        Compliance Equivalent Volume (Vas)
        13 Liters
        Overall Outside Diameter
        149 mm
        Overall Depth
        70.9 mm
        Baffle Cutout Diameter
        113 mm
        # Mounting Holes
        4
        Mounting Hole Diameter
        3.2 mm

        Show more
