        Product description Sure Electronics AA-AB31512 Amplifier module

        If you absolutely have to have 500 clean watts of stereo power, look no further than this amplifier board. It integrates high performance class D audio amplifier driver IRS2092SPBF and 200V Single N-Channel HEXFET Power MOSFET IRFB4227 by using one channel half bridge topology.



        Highlights

        • Self-oscillating half-bridge topology
        • Capable of 500W RMS output @ 4 Ohm continuously
        • Requires 55 to 65 VDC power supply



        Product details

        Sure Electronics AA-AB31512 1x500W IRS2092 4 Ohm Class D Audio Amplifier Board



        If you absolutely have to have 500 clean watts of stereo power, look no further than this amplifier board. It integrates high performance class D audio amplifier driver IRS2092SPBF and 200V Single N-Channel HEXFET Power MOSFET IRFB4227 by using one channel half bridge topology.



        Two 55 to 65 VDC high-voltage power supplies are required for operation; each power supply dedicates its full output potential to a single rail for maximum output. This results in increased high-fidelity output, high dynamic range, low distortion, and a wide 20 to 22,000 Hz frequency response.



        Connection:





        Typical Performance Graphs:

        Frequency response:





        Noise Floor:





        THD+N VS Frequency:





        Thermal Image:





        All parameters were tested with Rohde & Schwarz UPV audio analyzer and AP AUX0025 filter with AES17 filter enabled.

        Show more

        Specifications

        Article number
        AA-AB31512
        EAN
        0691046948755
        Rated power output
        1 x 500 watts at 4 ohms
        Minimum load
        4 ohms
        Efficiency
        88 - 93 %
        Signal-to-noise ratio (SNR)
        98 dB
        Distortion

        0.03 % at 4 ohms, 1 watts, 1 kHz
        0.04 % at 4 ohms, 10 watts, 1 kHz

        Frequency response
        20 - 20,000 Hz
        Gain
        30 dB
        Input sensitivity
        1.44 V
        Input impedance
        3,3k ohms
        Amplifier Classification
        Class D
        Circuit Topology
        Infineon Technologies IRS2092
        Speaker output channels
        1
        Input connection type
        RCA
        Speaker output connection type
        Screw terminals
        DSP function
        -
        Bluetooth
        -
        EQ Adjustment
        -
        Power Requirements
        2 x 55 - 65 VDC
        Power inlet connector
        Screw terminals
        Current limit
        9.1 A
        Under/over voltage protection
        Dimensions (L x W x H)
        152.4 x 114.3 x 63.5 mm
        Mounting hole spacing
        -
        Mounting hole diameter
        3.8 mm
