        R 10 S - 4 4" Full-Range Speaker 4 Ohm

        Visaton R 10 S - 4 4" Full-Range Speaker 4 Ohm

        €11,95

        6 In stock

        Add to cart

        Visaton R 10 S - 4 4" Full-Range Speaker 4 Ohm

        1 reviews
        5 from 5
        1 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Visaton
        Show all Full-range woofer
        4" | 4 Ω
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        € 9,88€ 11,95 6 In stock
        • -5% Purchase 4 for only € 11,35 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm
        R 10 S - 4 4" Full-Range Speaker 4 Ohm

        Product description Visaton R 10 S - 4 Full-range Woofer

        10 cm (4") fullrange speaker offers great frequency response and sensitivity in a compact package. Great for point-source applications with a limited amount of mounting depth space.



        Highlights

        • Full-range frequency response from 100 to 13,000 Hz
        • Thin mount profile with a mounting depth of 36 millimeters
        • High 90 dB sensitivity



        Product details

        Visaton R 10 S 4" Full-Range Speaker 4 Ohm



        Designed or electronic devices, and to be used in the ceiling structures of rail cars and buses, Visaton's R 10 S full-range speaker has very linear response from 150 to 10,000 Hz. The slim design features a depth of 36 millimeters for shallow mounting. High sensitivity and good power handling combine for more output than many midrange drivers this size, while the paper cone and accordion surround create a more natural, classic sound that is pleasing to most peoples' ears. A square steel mounting plate eliminates the need for a baffle recess, while the mounting slots can accept a wider range of mounting diameters.



        Visaton article code: 2036

        Show more

        Specifications

        Article number
        R 10 S - 4
        EAN
        4007540020365
        Woofer Type
        Full-Range
        Nominal Diameter
        4"
        Power Handling (RMS)
        20 Watts
        Power Handling (max)
        30 Watts
        Impedance (Z)
        4 ohms
        Sensitivity (SPL at 1m / 2.83V)
        93 dB
        Frequency Response
        100 - 13,000 Hz
        Voice Coil Diameter
        15 mm
        DC Resistance (Re)
        3.4 ohms
        Voice Coil Inductance (Le)
        0.2 mH
        Resonant Frequency (Fs)
        160 Hz
        Mechanical Q (Qms)
        5.53
        Electromagnetic Q (Qes)
        1.96
        Total Q (Qts)
        1.45
        Diaphragm Mass Inc. Airload (Mms)
        1.9g
        Surface Area of Cone (Sd)
        56 cm2
        BL Product (BL)
        1.9 Tm
        Compliance Equivalent Volume (Vas)
        1.9 liters
        Maximum Linear Excursion (Xmax)
        0.5 mm
        Cone / Diaphragm Material
        Paper
        Surround Material
        Treated Paper
        Basket / Frame Material
        Steel
        Magnet Material
        Ferrite
        Overall Outside Diameter
        94 mm
        Overall Depth
        36 mm
        Baffle Cutout Diameter
        93 mm
        Bolt Circle Diameter
        117 mm
        # Mounting Holes
        4
        Mounting Hole Diameter
        5 mm
