        BM2288 8'' Bass-midwoofer 8 ohm

        Volt Loudspeakers BM2288 8'' Bass-midwoofer 8 ohm

        €249,95

        8 In stock

        Add to cart

        Volt Loudspeakers BM2288 8'' Bass-midwoofer 8 ohm

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Volt Loudspeakers
        Show all Bass-mid woofer
        8" | 8 Ω
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        € 206,57€ 249,95 8 In stock
        • -5% Purchase 4 for only € 237,45 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Same day shipping
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm
        BM2288 8'' Bass-midwoofer 8 ohm

        Product description Volt Loudspeakers BM2288 Bass-midwoofer

        The Volt Loudspeakers BM2288 is an 8" bass-midwoofer designed to deliver powerful bass performance along with an extended, low coloration midrange. This driver is ideal for use in high-fidelity 2-way systems, providing exceptional sound quality and reliability.



        Highlights of the Volt Loudspeakers BM2288 Bass-midwoofer

        • 8" doped polymer cone for minimal coloration
        • Symmetrical field magnet system for large linear excursions
        • Double rear suspensions for transient stability
        • Optimized Thiele-Small parameters for small enclosures



        Product details of the Volt Loudspeakers BM2288 Bass-midwoofer

        Volt Loudspeakers BM2288 Bass-midwoofer



        The BM2288 features an 8" critically doped polymer cone, which is designed to minimize coloration and deliver clear, accurate sound. The symmetrical field magnet system allows for large linear excursions, essential for handling deep bass frequencies with low distortion. Double rear suspensions provide excellent transient stability even at high drive levels, ensuring consistent performance.



        This driver operates within a frequency range of 30 to 3000 Hz, with a sensitivity of 89 dB/W/m and a power handling capacity of 150W AES. Its Thiele-Small parameters are optimized for use in relatively small enclosures, making it suitable for compact monitors and 2-way systems. The BM2288 is available in both 8 ohm and 16 ohm versions, offering flexibility for various system configurations.

        Show more

        Specifications

        Article number
        BM2288
        EAN
        9505657875625
        Woofer Series
        Studio range
        Woofer Type
        Bass Mid driver
        Nominal Diameter
        8 "
        Power Handling (RMS)
        150 Watts
        Impedance (Z)
        8 or 16 Ω
        Sensitivity (SPL at 1m / 2.83V)
        89 dB
        Frequency Response
        30 - 3000 Hz
        Voice Coil Diameter
        38 mm
        DC Resistance (Re)
        5.8 Ω
        Voice Coil Inductance (Le)
        1.26 mH
        Resonant Frequency (Fs)
        35 Hz
        Mechanical Q (Qms)
        5.80
        Electromagnetic Q (Qes)
        0.38
        Diaphragm Mass Inc. Airload (Mms)
        40 g
        Mechanical Compliance of Suspension (Cms)
        0.50 mm/N
        Surface Area of Cone (Sd)
        213.82 cm²
        Volume of Displacement (Vd)
        86 cm³
        BL Product (BL)
        11.7 N/A
        Compliance Equivalent Volume (Vas)
        32 Litres
        Maximum Linear Excursion (Xmax)
        ± 12.5 mm
        Cone / Diaphragm Material
        Coated Black HIPS
        Surround Material
        Rubber
        Voice Coil Wire Material
        Copper
        Basket / Frame Material
        Diecast Aluminium
        Overall Outside Diameter
        214 mm
        Overall Depth
        106 mm
        Baffle Cutout Diameter
        192 mm
        Bolt Circle Diameter
        218 mm
        # Mounting Holes
        4
        Mounting Hole Diameter
        5.2 mm

        Show more

        Reviews

        0 reviews
        Review this product

        There are no reviews written yet about this product..
