      Illuminator R3004/602010 Tweeter Ring Radiator

      Scan-Speak Illuminator R3004/602010 Tweeter Ring Radiator

      €189,95

      4 In magazzino

      Aggiungi al carrello

      Scan-Speak Illuminator R3004/602010 Tweeter Ring Radiator

      1 reviews
      5 da 5
      1 reviews
      5 stars
      100%
      4 stars
      0%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      Marchio: Scan-Speak
      Mostra tutti Tweeters Scan-Speak
      1" | 4 Ω
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      € 189,95 4 In magazzino
      • -5% Acquista 4 per soli € 180,45 per pezzo
      +-
      Aggiungi al carrello
      • Spedizione gratuita a partire da € 199
      • Ordinato ora, spedito oggi
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator
      Illuminator R3004/602010 Tweeter Ring Radiator

      Descrizione del prodotto Scan-Speak Illuminator R3004/602010 Tweeter Ring Radiator

      Highlights

      • 1" Soft Ring Dome
      • Ring Neodymium Magnet
      • Patented Symmetrical Drive (SD-2) motor
      • Patented Phase Plug Design
      • Aluminum Face Plate and Housing
      • Sound Transparent Protective Grill
      • Deep Non Resonant Alu Rear Chamber
      • 9mm (2.44") diameter flange with 55.1mm (2.17") depth (see drawing below)
      • Excellent choice for both home hi-fi and autosound applications where depth is not an issue



      Product details

      Scan-Speak Illuminator R3004/602010 1" Ring Radiator



      The large-roll surround and textile dome diaphragm provide a flat frequency response to above 30KHz with outstanding off-axis dispersion. The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability.



      The R3004-602010 is optimized to offer small package sizes that can fit into tight spaces such as compact cabinets and automotive trim pieces where you have extra depth. The back chamber is die cast in aluminum and designed with a contoured shape that functions as a heat sink in high power applications.



      Specifications: Compliance Equivalent Volume (Vas): 0.0007 ft.³ • BL Product (BL): 1.7 Tm • Mechanical Compliance of Suspension (Cms): 0.41 mm/N • Diaphragm Mass Inc. Airload (Mms): 0.35 g • Maximum Linear Excursion (Xmax): 0.2 mm • Surface Area of Cone (Sd): 5.6 cm2

      Specifiche

      Numero dell'articolo:
      R3004/602010
      EAN
      0696277268351
      Tipo di tweeter
      Ring Radiator
      Serie del tweeter
      Illuminator Series
      Diametro del cono / cupola
      25 mm | 1"
      Gestione della potenza (RMS)
      50 Watts
      Gestione della potenza (max)
      130 Watts

      Show more

      Recensioni

      1 reviews
      Recensisci questo prodotto
      5 di 5
      -
      Da Zoltán on 23 Ottobre 2024
      Illuminator R3004/602010 Tweeter Ring Radiator
