      Illuminator R3004/662000 Tweeter Ring Radiator

      Scan-Speak Illuminator R3004/662000 Tweeter Ring Radiator

      €269,95

      4 In magazzino

      Aggiungi al carrello

      Scan-Speak Illuminator R3004/662000 Tweeter Ring Radiator

      2 reviews
      5 da 5
      2 reviews
      5 stars
      100%
      4 stars
      0%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      Marchio: Scan-Speak
      Mostra tutti Tweeters Scan-Speak
      1" | 4 Ω
      Illuminator R3004/662000 Tweeter Ring Radiator
      Illuminator R3004/662000 Tweeter Ring Radiator
      Illuminator R3004/662000 Tweeter Ring Radiator
      Illuminator R3004/662000 Tweeter Ring Radiator
      € 269,95 4 In magazzino
      • -5% Acquista 4 per soli € 256,45 per pezzo
      +-
      Aggiungi al carrello
      • Spedizione gratuita a partire da € 199
      • Ordinato prima delle 16:00, spedito oggi
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Illuminator R3004/662000 Tweeter Ring Radiator
      Illuminator R3004/662000 Tweeter Ring Radiator
      Illuminator R3004/662000 Tweeter Ring Radiator
      Illuminator R3004/662000 Tweeter Ring Radiator

      Descrizione del prodotto Scan-Speak Illuminator R3004/662000 Tweeter Ring Radiator

      Highlights

      • 1" Ring Dome Diaphragm
      • Patented Symmetrical Drive (SD-2) motor
      • Diffraction Damping Rubber Front
      • Patented Phase Plug Design
      • AirCirc Motor Design with 6 Neo magnets
      • Die Cast Rubber Painted Alu Face Plate



      Product details

      Scan-Speak Illuminator R3004/662000 1" Ring Radiator



      The Illuminator tweeters continue with the heritage of the renowned Revelator D29. The large-roll surround and textile dome diaphragm provide a flat frequency response to above 30KHz with outstanding off-axis dispersion. The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability.



      The R3004 builds on the experience of the one-inch R29 ring radiator, resulting in low resonance frequency, superb vocal rendition and excellent imaging at all listening locations. Scan-speak’s unique AirCirc Magnet System -- named for the way it optimizes air flow within the chamber – rearranges the traditional magnet structure from a single magnet to an open magnetic circuit comprised of six separate neodymium slugs. This, in combination with the chamber, results in the elimination of the reflections and resonances that compromise the performance of traditional motors.



      Specifications: Compliance Equivalent Volume (Vas): 0.0003 ft.³ • BL Product (BL): 2.3 Tm • Mechanical Compliance of Suspension (Cms): 0.31 mm/N • Diaphragm Mass Inc. Airload (Mms): 0.35 g • Maximum Linear Excursion (Xmax): 0.2 mm • Surface Area of Cone (Sd): 5.6 cm2

      Specifiche

      Numero dell'articolo:
      R3004/662000
      EAN
      0696277268368
      Tipo di tweeter
      Ring Radiator
      Serie del tweeter
      Illuminator Series
      Diametro del cono / cupola
      25 mm | 1"
      Gestione della potenza (RMS)
      90 Watts
      Gestione della potenza (max)
      150 Watts

      Show more

      Recensioni

      2 reviews
      Recensisci questo prodotto
      5 di 5
      -
      Da Thomas on 19 Marzo 2023
      5 di 5
      Koper heeft geen omschrijving achtergelaten.
      Da Patrick L. on 15 Febbraio 2020
