    Designer DSA270-PR Radiatore Passivo

    Dayton Audio Designer DSA270-PR Radiatore Passivo

    €63,95

    10+ In magazzino

    Dayton Audio Designer DSA270-PR Radiatore Passivo

    2 reviews
    5 da 5
    2 reviews
    5 stars
    50%
    4 stars
    50%
    3 stars
    0%
    2 stars
    0%
    1 stella
    0%
    Leggi le recensioni
    Marchio: Dayton Audio
    € 63,95 10+ In magazzino
    • -5% Acquista 4 per soli € 60,75 per pezzo
    • Spedizione gratuita a partire da € 199
    • Ordinato ora, spedito oggi
    • Minimo cinque anni di garanzia
    • Periodo di recesso di 45 giorni per i resi
    • Dicono di noi:
    Richiedi preventivo

    Descrizione del prodotto Dayton Audio Designer DSA270-PR Radiatore Passivo

    The Dayton Audio Designer Series passive radiators are excellent general-purpose passives suitable for replacement or for new construction. Built to be a perfect match for the Designer Series drivers, these passive radiators feature the same steel frame, rubber surround, and anodized aluminum cone making them visually identical.



    Highlights

    • Perfect match for Dayton Audio's aluminum cone Designer Series drivers
    • Allows tuning small enclosures lower than using conventional ports
    • Rear mounted screw allows easy mass adjustment for custom tuning
    • Cosmetic frame edge looks great even when surface mounted



    Product details

    Dayton Audio DSA270-PR 10" Designer Series Aluminum Cone Passive Radiator

    The Dayton Audio Designer Series passive radiators are excellent general-purpose passives suitable for replacement or for new construction. A built-in mass disc offers a good starting point for most designs, and a convenient M5 threaded hole (screw included) allows different types of weights to be added if desired. Cosmetically and mechanically, these passives match Dayton Audio's Designer Series drives, with a black anodized aluminum cone and medium-roll rubber surround for clean excursion and long life. The possibilities with these passives are endless, from full size tower designs to compact subwoofer systems.



    Specifications: • Fs: 21.9 Hz • Vas: 3.74 cu. ft. • Qms: 5.26 • Cms: 0.60 mm/N • Rms: 2.3 kg/s • Mms: 88.4 g • Sd: 353 sq. cm. • Xmax: 11 mm • Dimensions: Overall diameter: 10.63", Cutout diameter: 8.94", Depth: 2.87".



    Note: Adding mass to the passive radiator will decrease Fs and increase Qms.

    Tip: As a general rule, the passive radiator(s) should have at least double the displacement of air (Vd) as the active woofer(s)/subwoofer(s) in the system.

    To calculate Vd: Sd x Xmax = Vd

    Specifiche

    Numero dell'articolo:
    DSA270-PR
    EAN
    0848791005077
    Serie del woofer
    Dayton Audio Designer series
    Tipo di woofer
    Passive Radiator
    Diametro nominale
    10"
    Frequenza di risonanza (Fs)
    21.9 Hz
    Fattore di merito meccanico (Qms)
    5.26

    Show more

    4 di 5
    The data sheet gives bad values for Xmax and Vd. The correct values are the same as for the DSA 270 loudspeaker Xmax=5.5mm and Vd=194.1cm3
    Da Tonovec on 11 Giugno 2023
    5 di 5
    No description was given
    Da Laurynas M. on 17 Maggio 2019
