        C90-6-724 5'' Cell Mid-range

        Accuton C90-6-724 5'' Cell Mid-range

        €629,95

        10 Op voorraad

        Accuton C90-6-724 5'' Cell Mid-range

        1 reviews
        5 van 5
        1 reviews
        5 sterren
        100%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: Accuton
        € 520,62€ 629,95 10 Op voorraad

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Nu besteld, morgen bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Voor- en nadelen

        Volgens onze specialisten
        • A proprietary clamping technique provides easy mounting and adapting to individual frontplates.

        Productomschrijving Accuton C90-6-724 Cell Mid-range

        The C90-6-724 is a 5 inch bass - midrange driver with ceramic dome, being the first in an entirely new approach to accuton speaker design. An ideal acoustical center has been achieved, which is identical with our tweeters.



        Highlights

        • full featured cell concept
        • ideal acoustical center
        • no reflections at the backside
        • Underhung motor design
        • 200 HZ - 6000 HZ



        Product details

        Accuton C90-6-724 5'' Cell Mid-range



        An ideal acoustical center has been achieved, which is identical with our tweeters. Its novel designed underhung motor does not cover the backside of the dome, eliminating the chance for reflections and energy storage. The ultra-hard ceramic dome is made of a material that is extremely stiff and light, which makes it ideal for high-frequency reproduction. The ceramic material used in the dome is also highly resistant to temperature changes and humidity, which makes it ideal for use in high-end audio systems.



        A proprietary clamping technique provides easy mounting and adapting to individual frontplates. The low loss rubber surround and a thin fabric spider center the moving parts with high linearity. We recommend the C90-6-724 for an application from 150 Hz – 6000 Hz.

        Toon meer

        Specificaties

        Artikelnummer
        C90-6-724
        EAN
        8785256847532
        Woofer type
        Midrange driver
        Nominale diameter
        123.60 mm, 5 Inch
        Belastbaarheid (RMS)
        100 Watt
        Impedantie (Z)
        8 Ohm
        Gevoeligheid (SPL bij 1m / 2.83V)
        89 dB
        Frequentierespons
        60 - 6.000 Hz
        Spreekspoeldiameter
        80 mm
        Gelijkstroomweerstand (Re)
        5.8 Ohm
        Spreekspoelinductie (Le)
        0.14 mH
        Resonantiefrequentie (Fs)
        82.6 Hz
        Mechanische Q (Qms)
        5.47
        Elektrische Q (Qes)
        0.58
        Totale Q (Qts)
        0.52
        Bewegende massa (Mms)
        8.9 g
        Compliantie van de ophanging (Cms)
        0.65 mm/N
        Krachtsfactor (BL)
        6.1 N/A
        Equivalentvolume (Vas)
        5.1 Liter
        Maximale excursie (Xmax)
        4 mm
        Driver's Mechanical Losses (Rms)
        0.68 kg x s
        Cone / Diaphragm Material
        Cu
        Totale buitendiameter
        123.6 mm
        Totale diepte
        55 mm
        Montagegatdiameter
        124 mm
